UNIOP ETOP33C-0050-S
1. Product Overview
The UNIOP ETOP33C-0050-S is a high-performance Human Machine Interface (HMI) Operator Panel designed for industrial automation applications. It belongs to the UniOP eTOP series developed for machine control, process monitoring, and operator interaction. The device integrates a color touchscreen display, embedded control electronics, communication interfaces, and industrial-grade protection features to provide a complete visualization and control solution.
The serves as a core interface between operators and automation systems, enabling users to monitor equipment status, adjust operating parameters, manage system alarms, and establish communication with PLC controllers. Equipped with a 12.1-inch TFT color display, SVGA resolution, built-in Ethernet, USB support, and diverse flexible industrial communication options, it is perfectly adapted to medium and large-scale automation machines that demand high-definition visualization and stable, reliable operation.
2. Technical Specifications
|
Item
|
Description
|
|---|---|
|
Product Type
|
Industrial HMI Touch Panel
|
|
Display Type
|
12.1-inch TFT Color LCD
|
|
Resolution
|
800 × 600 pixels (SVGA)
|
|
Touchscreen Type
|
Resistive Touchscreen
|
|
Display Colors
|
Up to 64K colors
|
|
User Memory
|
64 MB
|
|
Power Supply
|
24 VDC (18–30 VDC)
|
|
Ethernet Interface
|
10/100 Mbps
|
|
USB Interface
|
USB Host
|
|
Serial Communication
|
RS-232 / RS-485 / RS-422
|
|
Front Protection
|
IP65
|
|
Mounting Type
|
Panel Installation
|
|
Programming Software
|
UniOP Designer
|
|
Application Area
|
Industrial automation and machine control
|
3. Main Features and Functions
3.1 Advanced Touchscreen Visualization
is equipped with a 12.1-inch TFT color graphic display featuring SVGA high resolution, which presents clear, detailed, and intuitive industrial process visualization. The professional resistive touchscreen is tailored for complex industrial scenarios, supporting stable operation even when operators wear gloves.
Operators can efficiently complete the following operations via the touchscreen interface:
-
Real-time viewing of machine operating conditions
-
Precise adjustment of production parameters
-
Dynamic monitoring of process variables
-
Quick access and query of alarm information
-
Intuitive control of connected automation equipment
3.2 Powerful Communication Capability
Designed with flexible and diverse industrial communication protocols, the eTOP40C can be flexibly connected to multiple types of automation equipment, adapting to different industrial network architectures. The built-in high-speed Ethernet interface greatly enhances device connectivity in modern automation systems, facilitating project downloading, remote equipment management, and real-time data exchange.
Core supported communication functions:
-
Multi-protocol PLC communication
-
Serial device connection and data transmission
-
Stable Ethernet networking communication
-
Expandable optional fieldbus modules
3.3 Rich HMI Application Functions
Supported by the professional UniOP Designer programming software, the eTOP40C integrates comprehensive advanced HMI functions, providing engineers with powerful and convenient tools to customize exclusive operator interfaces, optimize operation processes, and improve production efficiency.
Main available application functions:
-
Free graphical screen design and editing
-
Intelligent alarm classification and management
-
Historical event recording and query
-
Production recipe storage and management
-
Real-time trend data display and analysis
-
Automatic industrial data acquisition and sorting
-
Multi-level password protection and authority management
-
Multi-language switching for global application
4. Hardware Structure and Components
adopts an integrated modular hardware design, with compact internal structure and stable performance. The whole device consists of four core hardware modules:
4.1 TFT Display and Touch Module
The front-end integrated assembly integrates a high-definition color TFT screen and a durable resistive touch panel, providing accurate visual feedback and sensitive operator input functions. The large-size high-resolution display area can clearly present complex process graphics, real-time trend charts, and equipment layout diagrams, realizing intuitive industrial monitoring.
4.2 Embedded Processing Unit
The built-in high-performance industrial processor undertakes core tasks such as HMI program operation, multi-task communication management, and operator instruction processing. It provides stable and sufficient computing performance to ensure smooth operation of various visualization and control applications in complex industrial environments.
4.3 Communication Interface Board
The independent communication module is equipped with multiple universal interfaces, covering mainstream industrial communication methods. It supports efficient connection and data interaction with PLCs, engineering configuration equipment, industrial network systems and peripheral devices, realizing flexible equipment networking and function expansion.
4.4 Memory and Storage System
The built-in high-capacity independent memory is used to store HMI application programs, graphical interface resources, production recipe data, and system configuration parameters. The device can operate independently for a long time without external computer assistance, ensuring the continuity and stability of on-site industrial operation.
5. Application Fields
With its excellent stability, rich functions and strong compatibility, the UNIOP eTOP40C HMI panel is widely used in various industrial automation scenarios, covering manufacturing, process control, building automation and other fields.
5.1 Manufacturing Equipment
-
Automated assembly machines
-
Intelligent packaging systems
-
Automated production lines
-
Automatic inspection and testing equipment
5.2 Process Automation
-
Real-time industrial process monitoring
-
Online production parameter adjustment
-
Full-cycle equipment status visualization
-
Dedicated control system interactive interface
5.3 Building and Facility Automation
-
Intelligent HVAC control systems
-
Building energy consumption real-time monitoring
-
Public facility intelligent management interface
5.4 Industrial Machine Control
-
Textile industrial machinery
-
Food processing and production equipment
-
Material handling and conveying systems
-
Customized special automation machinery
————————————————————————————————-
