UniOp etop05-0045 6ZA1040-7BE10 Card Module

UniOp etop05-0045 (also known as ETT-VGA-0045) is a small to medium-sized compact HMI solution in the UniOp series, commonly used in OEM equipment and on-site control panels. Integrating LCD display and touch control functions, it is designed to provide a reliable local monitoring and operation interface.

UniOp etop05-0045 6ZA1040-7BE10

1. Overview

2. Core Specifications

Specification Category	Detailed Specifications
Display	5.7-inch STN LCD (Grayscale or Blue-White Screen)
Resolution	320×240 Pixels
Backlight	CCFL (Cold Cathode Fluorescent Lamp)
Touch Method	Resistive Touch Screen (supports multiple touch methods, including resistive, infrared, etc.)
Communication Interface	Supports RS232 and RS485 (some versions)
Operating Temperature	0℃ – 50℃
Storage Temperature	-20℃ – 60℃
Protection Level	IP65 (Dustproof and Waterproof)
Power Supply Voltage	24V DC

3. Product Features

Compact and Integrated: Adopts Panel Mount installation, with a small size, suitable for integration into equipment panel interiors.
Robust and Durable: Features IP65 protection level, capable of long-term stable operation in industrial environments with much dust or water mist.
Multi-Protocol Compatibility: Although mainly communicating via RS232/RS485, it supports multiple industrial protocols, facilitating data interaction with mainstream PLCs.
User-Friendly: Cooperating with UniOP Designer 6 or eDesigner software, it supports rich graphic display, alarm management and recipe processing functions.

4. Structure and Composition

LCD Display Module: Responsible for the presentation of graphical interfaces.
Touch Panel: Resistive touch sensing layer, realizing human-computer interaction.
Main Control Circuit Board: Responsible for processing user input and executing logic control.
Communication Interface Board: Integrates RS232/RS485 interfaces for communication with upper computers or PLCs.
Power Management Module: Adapts to 24V DC power supply and provides internal voltage stabilization.

5. Typical Application Fields

OEM Equipment: Local control panels for equipment such as industrial filling machines, packaging machines, textile machinery, etc.
On-Site Monitoring: On-site equipment that requires real-time monitoring and parameter adjustment.
Industrial Automation: Serves as an auxiliary display and control terminal, working in coordination with the main control PLC.

6. Installation and Maintenance Recommendations

Installation Method: It is recommended to adopt Panel Mount installation. Ensure that the threaded holes of the installation panel are aligned with the equipment panel, and fix them with stainless steel screws.
Wiring Check: When connecting RS232/RS485, it is necessary to confirm that the communication wire sequence (TX/RX/GND) is correct to avoid communication failures.
Environmental Adaptation: In humid or dusty environments, ensure the cabinet tightness to give full play to the IP65 protection advantage.
Regular Maintenance: Regularly clean the surface of the touch screen to avoid dust and chemical cleaning agents corroding the touch layer.

————————————————————————————————-
