Overview

• Display Screen: 4.3-inch TFT display with a resolution of 480×272, equipped with full-color LED backlight for vivid and clear visual presentation
• Processor: ARM Cortex-A8 processor with a main frequency of 600 MHz, ensuring fast response and stable operation
• Power Supply: 24VDC standard industrial power supply, compatible with mainstream industrial power systems
• Integrated Interfaces: Dual 100Mb Ethernet ports with built-in switching function, USB interface, serial port and MPI interface, meeting diverse industrial communication demands
• Expansion Capability: Supports optional plug-in modules for field bus and network system expansion, and features SD card storage expansion
• Protection & Environmental Parameters (eTOP500 Series): Operating temperature range from 0℃ to +50℃, storage temperature range from -20℃ to +70℃, relative humidity of 5%-85% non-condensing, and front panel with IP66 protection grade for excellent environmental adaptability

Product Features

• Adopts innovative mechanical design and full-metal enclosure structure, featuring solid durability and anti-interference performance
• High-performance touchscreen HMI with full-color LED display, delivering intuitive and high-definition operation vision
• Supports gateway function, remote application installation and remote assistance, greatly improving equipment maintenance efficiency
• All circuit boards are coated with special protective coating to achieve moisture-proof and anti-corrosion effects, extending service life
• Comes with a 5-year official warranty, providing long-term reliable usage guarantee
• Optional integrated IEC 61131-3 standard PLC (compatible with CODESYS V2 or V3) for flexible function expansion
• The front panel is available in white, black and silver colors, with customized versions for special application scenarios
• Built-in dual 100Mb Ethernet ports with switching function, effectively enhancing industrial communication stability and expandability

Structure and Composition

Application Fields

• Industrial Automation Control: Realizes status display and parameter monitoring for PLCs and various automated control equipment
• Process Control and Monitoring: Applied in energy, chemical, pharmaceutical and other industries for process parameter display, data recording and alarm management
• Manufacturing and Assembly Line Management: Monitors equipment operating status and optimizes production processes for automated production lines
• Logistics and Warehousing Automation: Provides real-time status display and manual operation feedback for automatic conveying, sorting and warehousing systems
• OEM and Custom Equipment Integration: Features strong compatibility and flexibility, suitable for embedded integration in various customized automated equipment
