Product Type:Discrete Output Card

LocalBus power rating:12 VDC at 150 mA

Bussed Field Power rating:24 VDC at 3.2 A

Card Terminal block key position:B4

Weight:0.2 kg

Series:DeltaV

Module Category:Control Systems

    The EMERSON KJ3204X1-BA1 Discrete Output Card is a critical component of the DeltaV System, designed to handle complex industrial control scenarios with precision and reliability. Its compact design ensures efficient space utilization in any industrial setup.

    Featuring a robust +12 VDC at 150 mA LocalBus power rating and a 24 VDC at 3.2 A Bussed Field Power rating, this card supports a wide range of devices without compromising performance or stability.

    With its B4 terminal block key position, the card offers flexibility in wiring and easy maintenance. The card’s ability to deliver up to 16 outputs at 20 mA per channel makes it suitable for applications requiring high output density.

    The inclusion of a 24 VDC @ 2 A relay rating ensures that the card can handle demanding loads, providing a fail-safe operation in critical systems. The RS-485 communication interface facilitates seamless data exchange with other system components.

    Operating within a temperature range of -20°C to +55°C during operation and -40°C to +70°C for storage, this card is designed for durability and reliability across various industrial environments.
