Current Range (A):9-45 A

Protection Type:Overload

Operating Voltage (V):AC 380-460 V

Operating Frequency (Hz):50/60 Hz

Contact Configuration:3P+L+N

Relay Type:Mechanical

Insulation Class:Class 1

Enclosure Rating:IP20

Ambient Temperature Range:-20°C to +50°C

    The Omron 193-EC5DD E3 Plus 9-45 A Overload Relay is a precision engineered solution designed to monitor and control current flow within industrial circuits. Its robust construction and adjustable overload sensitivity make it an ideal choice for protecting against damage caused by overloads, thereby enhancing system reliability and longevity.

    Equipped with advanced circuitry, this relay ensures quick and accurate response times, enabling immediate disconnection when current exceeds safe limits. This prevents potential hazards and extends the lifespan of connected equipment.

    Featuring a single pole double throw (SPDT) contact configuration, the relay offers versatile switching capabilities, facilitating both ON/OFF and normally open/normally closed operations. Its adjustable overload sensitivity allows users to customize protection levels according to specific application requirements.

    With an operating voltage range of 220V AC or 24V DC, this relay is compatible with a wide array of industrial power sources, ensuring seamless integration into various systems. The relay’s maximum current rating of 5A at 250V AC or 10A at 125V AC guarantees adequate protection under most conditions.

    The 193-EC5DD is designed with an IP20 protection class, offering basic splash and dust protection, suitable for most industrial settings. Its temperature resistance from -20°C to +60°C ensures stable operation across a broad range of environmental conditions.
