Number of Pins:12

Type of Terminal Block:Push-in terminal

Cable Type:Only copper wires

Wire Stripping Length:7 to 9 mm

Nominal Voltage:240 VAC

Max. Voltage:300 VAC

Color Coding:Standard and custom

Wiring Technology:Push-in technology

Labeling:Plain text and plain text labeling

Test Access:For standard probes

    The B&R X20TB12 Extended Control Module is meticulously engineered to provide unmatched flexibility and reliability in industrial automation environments. With its robust push-in terminal block design, it ensures effortless and tool-free assembly, saving you time and effort on setup.

    Each terminal connection can be labeled individually, allowing for easy identification and management of electrical circuits, which is particularly beneficial in complex systems where clear labeling is essential.

    The module supports plain text labeling, making it easier to read and understand the circuit configuration without the need for specialized label formats.

    Featuring test access for standard probes, maintenance and troubleshooting are streamlined, reducing downtime and enhancing system uptime. The inclusion of a special color coding scheme for 240V ensures that voltage levels are visually distinguished for safety.

    Built with only copper wires and featuring a stripped wire length of 7 to 9 mm, this module adheres to strict quality standards, ensuring compatibility and longevity with a wide range of cable types.

    The B&R X20TB12 is designed with user convenience in mind, making it an ideal choice for engineers and technicians seeking a reliable and efficient control solution for their automation projects.
