B&R 8X0005.00-1
1. Overview
The B&R 8X0005.00-1 is an industrial computer and central processor board manufactured by B&R Automation (Austria). As a member of the B&R Automation PC series, it is specially designed for industrial automation and control systems, featuring high reliability and modular architecture. A dedicated hardware dongle is required for the installation of the Automation Runtime real-time operating system on this device.
2. Technical Specifications
|
Parameter Item
|
Specification Data
|
|---|---|
|
Overall Dimensions
|
Approx. 120 mm × 250 mm × 270 mm
|
|
Weight
|
Approx. 6.0 kg
|
|
Power Supply
|
DC 9–36 V (wide voltage input)
|
|
Nominal Voltage
|
24 VDC ±25%, SELV (refer to products in the same series)
|
|
Nominal Current
|
6 A (refer to products in the same series)
|
|
Memory
|
2 GB / 4 GB / 8 GB (optional)
|
|
Communication Interfaces
|
Dual Gigabit Ethernet (2 × 10/100/1000 Mbps), USB 2.0/3.0
|
|
Display Interface
|
VGA Interface
|
|
Vibration Resistance
|
Supports vibration storage environment of 2–8 Hz
|
|
Dongle Port
|
Equipped
|
3. Product Features
Wide Voltage Power Supply: Supports a wide DC input voltage range of 9–36 V, adapting to diverse power supply conditions in complex industrial sites.
Multiple Memory Configurations: Provides flexible memory options including 2 GB, 4 GB and 8 GB to meet different operational demands.
Rich Interface Configuration: Comes with comprehensive interfaces including VGA display port, dual Gigabit Ethernet ports and USB 2.0/3.0 ports for versatile connection compatibility.
Modular Design: System expansion is achievable by connecting I/O modules via the X2X Link bus with the Logic Scanner 5SL189.6-1 card.
Industrial-Grade Reliability: Adaptable to harsh industrial environments with vibration interference, supporting 2–8 Hz vibration storage conditions.
4. Structure and Composition
This product is a complete industrial personal computer (IPC), and its core structural components are listed as follows:
-
Central Processor Board (Main Board Level): The core control unit of the device, undertaking main data processing and system operation tasks.
-
Memory Slots: Compatible with 2 GB, 4 GB and 8 GB memory modules for flexible capacity expansion.
-
Communication Interface Module: Integrates Gigabit Ethernet, USB, VGA and other mainstream interface modules to support multi-device data interaction.
-
Dongle Port: Dedicated port for license verification and installation of the Automation Runtime real-time operating system.
5. Application Fields
-
Printing Machinery: Applied to the computer control system of KBA printing presses to ensure stable and precise printing operation.
-
Industrial Automation Control: Serves as an on-site industrial control computer to undertake core control tasks of automated production lines.
-
Real-Time Control System: Cooperates with the Automation Runtime real-time operating system and X2X Link bus to realize high-speed I/O data communication and precise industrial control.
6. Installation and Maintenance
6.1 Installation Requirements
A matched hardware dongle must be installed in advance to support the normal installation and operation of the Automation Runtime real-time operating system. As a standard industrial computer, it is generally installed inside industrial control cabinets.
6.2 Power Supply Requirements
The device adopts DC 9–36 V wide voltage power supply, with 24 VDC recommended as the optimal operating voltage.
6.3 Maintenance Instructions
-
Multiple product versions are available for selection, including brand-new factory-sealed products, pre-owned products (fully cleaned, with worn parts replaced and professionally tested), and repaired products.
-
Some refurbished modules may not be equipped with complete accessories such as connectors, keys and user manuals.
-
During equipment maintenance, static protection measures must be taken, and the hardware dongle shall be properly protected to avoid damage or data loss.
6.4 Environmental Adaptability
The device can withstand and adapt to 2–8 Hz vibration storage environments, fully meeting the environmental adaptability requirements of on-site industrial production scenarios.
————————————————————————————————-
