1. Product Overview

2. Key Technical Parameters

• Power Supply Specification: Complies with the standard power supply requirements of the 3300/16 series (specific voltage parameters should refer to the system manual in combination with the specific chassis configuration).
• Weight: Approximately 2 kg (about 4.4 lbs).
• Dimension Requirement: Usually occupies one rack unit (1U) and needs to be installed on the left side of the cabinet (left side of the system monitor).
• Interface: Backplane connection, supplying power to each module inside the system through the backplane.

______________________________________________________________________________________________

3. Product Features

• High Reliability: Designed with industrial-grade components, it has long-term operation stability and is suitable for harsh industrial environments.
• Modular Design: As a standardized module, it is easy to replace and maintain.
• Compliance with Industry Standards: Conforms to the vibration monitoring system specifications of API 670 standard.

______________________________________________________________________________________________

4. Structure and Composition

• Power Conversion Circuit: Converts the input power into a stable voltage required by the system.
• Cooling System: Built-in heat sink or fan (depending on the specific model) to ensure safe operation in high-temperature environments.
• Connector: Used for electrical connection with the system backplane and other modules.

______________________________________________________________________________________________

5. Application Fields

• Oil and Gas: Oil drilling rigs, fracturing equipment, pumping units, etc.
• Energy and Power Generation: Gas turbines, steam turbines, generator sets.
• Heavy Industry and Manufacturing: Mining machinery, metallurgical equipment, reciprocating compressors, etc.
• Shipbuilding and Shipping: Marine engines and key transmission equipment.

______________________________________________________________________________________________

6. Installation and Maintenance

Installation Position

Wiring Requirements

Maintenance Points

• Regular Inspection: Check whether the fan of the power supply board (if any) is running normally and whether there is dust accumulation on the heat sink.
• Monitoring and Alarm: If a power supply abnormality alarm occurs in the monitoring system, first check the input and output voltage of this board.
• Replacement Suggestion: During system upgrade or major maintenance, it is recommended to use the original PWA86739-01U for replacement to ensure compatibility and protection level.
