1. Product Overview

2. Key Parameters

• Model: 3500/62
• Part Number: 163179-03
• Signal Input: Supports +4mA to +20mA current input or -10Vdc to +10Vdc voltage input (optional module type)
• Number of Channels: 6 analog input channels
• Power Supply: 24V DC
• Power Consumption: Approximately 5W.

______________________________________________________________________________________________

3. Product Features

• Multi-channel Monitoring: Equipped with 6 analog input channels, it can monitor changes of multiple measuring points (such as pressure, flow, temperature, liquid level, etc.) at the same time.
• Alarm Management: It can compare the actual measured value with the set threshold, trigger an alarm or drive a protection relay to prevent equipment damage.
• Communication Function: Supports RS-485 and Ethernet communication, facilitating remote data transmission and centralized monitoring.
• Reliability: Designed for harsh industrial environments, it supports high-reliability process monitoring needs.
• Modular Design: Easy to install and maintain, supporting multiple I/O module types and certification options.

_____________________________________________________________________________________________

4. Application Fields

• Energy and Power Generation: Monitoring of key equipment such as steam turbines, pumps and condensers in power plants.
• Petrochemical Industry: Process variable monitoring of reactors, distillation towers, etc. in refineries and chemical plants.
• Heavy Industry: Compressors, blowers, gearboxes, etc. in steel plants and machinery processing plants.
• General Industrial Processes: Any industrial scenario that requires real-time monitoring of parameters such as pressure, temperature, flow and liquid level.

______________________________________________________________________________________________

5. Installation and Maintenance

• Installation: As part of the 3500 series system, it is usually installed in a rack, working in coordination with other monitoring modules (such as vibration monitoring modules).
• Redundant Configuration: In critical applications, it is recommended to adopt a Triple Modular Redundancy (TMR) configuration, installing three monitors adjacent to each other to ensure that the system can still operate normally even if a single module fails.
• Maintenance: The modular design facilitates quick replacement; due to the adoption of non-contact measurement or isolated circuits, the maintenance cost is relatively low.
