1. Overview

2. Core Parameters

3. Product Features

• High-precision Monitoring: Uses high-precision sensors to monitor equipment status in real time, ensuring that signals can be captured at the initial stage of an abnormality.
• Rapid Response: Once an emergency shutdown command is triggered, the system responds extremely quickly and can execute the shutdown operation within milliseconds.
• Modular Design: Adopts a modular structure design, facilitating on-site rapid assembly, configuration and maintenance.
• High Reliability: Designed specifically for harsh industrial environments, it has high anti-interference ability and long service life.
• Integrated Communication: Supports industrial communication protocols such as PROFIBUS DP and Modbus RTU/TCP, facilitating integration into upper computer systems (such as PLC).

______________________________________________________________________________________________

4. Structure and Composition

• Sensor Interface Module: Used to connect various vibration, temperature or pressure sensors.
• Logic Processing Unit: Built-in microprocessor (about 100MHz), responsible for real-time data processing and judgment.
• Output Relays: Usually equipped with 5 relays (4 of which are used for system logic alarms, and 1 is used to reflect the status of the protection path).
• Communication Interface: Such as M12 connector, responsible for communication with PLC or upper computer.

______________________________________________________________________________________________

5. Application Fields

• Power Industry: Condition monitoring and protection of generators, transformers and their auxiliary equipment.
• Petrochemical Industry: Safety protection of key rotating machinery such as compressors, pumps and heat exchangers.
• Industrial Manufacturing: Used for any high-value rotating equipment that requires precise monitoring and rapid shutdown.

______________________________________________________________________________________________

6. Installation and Maintenance

Installation Recommendations

• Environmental Requirements: Must be installed in a control cabinet that meets the IP20 protection level to avoid moisture and dust intrusion.
• Power Supply Confirmation: Ensure access to a stable 24V DC power supply.
• Wiring Specifications: Follow Bently Nevada’s original wiring manual to correctly connect sensor signal lines and communication lines.

Maintenance Recommendations

• Regular Inspection: Regularly check the tightness and insulation of all terminal blocks to ensure no looseness or corrosion.
• Function Test: Regularly perform system self-inspection, especially the on-off test of output relays, to ensure normal operation in case of actual faults.
• Seal Inspection: If the device contains seals (such as O-rings), check their integrity to prevent internal components from getting damp due to leakage.
