ATLAS PF4002-G-PB-HW
1. Overview
The PF4002-G-PB-HW is a medium and small power model in the PowerFlex 4000 series of drives. Designed with a compact structure, this series of drives is suitable for industrial scenarios that are cost-sensitive yet require high reliability. It is mainly used to control three-phase asynchronous motors, achieving precise speed and torque control as well as energy conservation and consumption reduction.
___________________________________________________________________________________________________________________________
2. Core Parameters
- Power Range: Typically 0.75 kW to 3 kW class.
- Voltage Level: Supports standard industrial voltages such as 200V, 230V, 400V, and 460V.
- Control Method: Built-in microprocessor control, supporting Vector Control.
- Control Modes: Supports Torque Control (TC), Speed Control (VC), and PID Control.
- Communication Interfaces: Built-in PROFINET interface, supporting industrial Ethernet; also equipped with USB and RS232 interfaces for parameter setting and local debugging.
___________________________________________________________________________________________________________________________
3. Product Features
- Fast Response Speed: Adopts a high-speed processor internally, with extremely short dynamic response time.
- Compact Structure: The hardware structure is designed to be compact, facilitating installation in narrow spaces or inside control cabinets.
- High Energy Efficiency: Supports torque limitation and regenerative braking functions to reduce energy consumption.
- Strong Expandability: Rich optional hardware components, allowing additional I/O interfaces or communication modules to be added according to requirements.
___________________________________________________________________________________________________________________________
4. Structure and Composition
- Control Unit: Core processor and memory chip, responsible for running control algorithms.
- Power Module: Responsible for motor power supply and power conversion.
- Communication Board: Built-in PROFINET interface, as well as USB and RS232 interfaces.
- Display Panel: Some models are equipped with LCD/LED displays for showing operating status.
___________________________________________________________________________________________________________________________
5. Application Fields
The PF4002-G-PB-HW is widely used in fields such as automobile manufacturing, electronic assembly, precision machinery, and automated production lines. It is usually used to drive chassis assemblies, assembly robotic arms, or other equipment that requires precise torque control.
6. Installation and Maintenance
- Installation: Due to its compact structure, it is recommended to install it in a well-ventilated control cabinet, avoiding direct sunlight or humid environments.
- Maintenance: During equipment operation, regularly check the tightness of the wiring and perform parameter calibration when necessary to ensure control accuracy.
————————————————————————————————-
