ATLAS PF4002-C-EIP-HW
1. Product Overview
The ATLAS PF4002-C-EIP-HW is a high-end tightening controller belonging to the Power Focus 4000 series. It is usually used with ATLAS COPCO Tensor series electric torque tools (such as Tensor ST, Tensor SL, Tensor DS). This model is equipped with an EtherNet/IP (EIP) industrial Ethernet interface, featuring powerful data processing capabilities and high automation integration.
_______________________________________________________________________________________________________
2. Core Specifications
|
Specification
|
Description
|
|---|---|
|
Model
|
PF4002-C-EIP-HW
|
|
Communication Protocol
|
EtherNet/IP (EIP)
|
|
Control Mode
|
Torque Control, Angle Control, Combined Control, Joint Angle Control, Sequence Control
|
|
Sensor Support
|
12V Torque Sensor, CAN Bus Sensor
|
|
Data Functions
|
Real-time Data Collection, Traceability, Alarm Log, Production Statistics, Process Monitoring
|
|
Scalability
|
Supports Multi-channel expansion, suitable for multi-station operations
|
_______________________________________________________________________________________________________
3. Product Features
- Multi-control Mode Support: Compatible with angle control, torque control, combined control and multi-step sequence control, which can adapt to complex assembly processes.
- Industrial-grade Communication: Integrated with EtherNet/IP interface, supporting seamless connection with upper computers such as PLC and MES systems to realize Industrial Internet of Things (IIoT).
- High Precision and Traceability: Equipped with high-precision control capability and powerful data recording function, meeting the requirements of high-reliability assembly.
- Modular and Compact Design: The hardware structure is compact, easy to install in the control cabinet, and supports highly scalable multi-station process control.
_______________________________________________________________________________________________________
4. Structure and Composition
- Main Controller: The main body of PF4002-C-EIP-HW, responsible for command calculation and execution.
- Connecting Harness: Used to connect torque sensors, actuators and upper computers.
- Software Platform: Usually matched with Atlas Copco Power Focus 4.0 software platform (including PC terminal and HMI terminal) for parameter setting, data monitoring and system debugging.
_______________________________________________________________________________________________________
5. Main Application Fields
- Aerospace Industry: Bolt connection of aircraft structural components and assembly of composite material connections.
- Automotive Manufacturing: High-precision tightening of key components such as engines, gearboxes and chassis.
- Railway and Construction Machinery: Assembly process control of large equipment components.
- New Energy Field: Such as bolt connection control of new energy vehicle power battery modules.
————————————————————————————————-
