ATLAS PF4002-C-DN-HW Digital Output Module

The ATLAS PF4002-C-DN-HW is a controller in the Power Focus 4000 series, specifically designed for high-precision tightening processes.

ATLAS PF4002-C-DN-HW

1. Overview

The ATLAS PF4002-C-DN-HW is a controller in the Power Focus 4000 series, specifically designed for high-precision tightening processes. It communicates with torque tools via the DeviceNet bus, enabling complex tightening sequences and real-time data traceability. It is a key equipment for realizing automated assembly processes.

_______________________________________________________________________________________________________

2. Specifications

Model: PF4002-C-DN-HW
Communication Interface: DeviceNet (DN)
Compatible Tools: Tensor series intelligent electric torque tools
Voltage Range: 120/180-240V AC
Control Modes: Torque Control, Angle Control, Combined Control, Multi-step Sequence

_______________________________________________________________________________________________________

3. Product Features

High-Precision Control: Supports torque control, angle control and combined control to ensure tightening quality.
DeviceNet Communication: Realizes real-time data interaction with torque tools, PLC and other equipment through DeviceNet bus.
Data Traceability: Equipped with real-time data collection, alarm log, production statistics and other functions to support process traceability.
Modular Design: Compact structure, easy to integrate into existing assembly lines.

_______________________________________________________________________________________________________

4. Structure and Composition

Control Unit: The core computing and control module, responsible for processing sensor data from tools.
Communication Module: Communication interface supporting DeviceNet bus.
Power Supply Module: Provides stable power supply for the system.
IO Interface: Used to connect external sensors or actuators.

_______________________________________________________________________________________________________

5. Application Fields

Automotive Manufacturing: Precision tightening of body, chassis and engine components.
Aerospace: High-precision assembly of engine components and body structures.
Mechanical Manufacturing: Assembly of precision mechanical components.
High-End Electronics: Assembly of electronic components with high torque requirements.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation

It needs to be fixed in a vibration-proof cabinet or chassis, and connected to the power supply and DeviceNet network. During installation, on-site electrical specifications should be followed to ensure good grounding.

Maintenance

Regularly check the communication lines and power interfaces, clean the dust inside the equipment, and back up the control parameters regularly. In case of communication failure, check the DeviceNet bus terminal resistance and line connection.

————————————————————————————————-
