Product Overview

Product Specifications

• Series Model: PF4000
• Product Code: G-PN-HW
• Main Functions: Torque Control, Motor Management, Communication Interface
• Compatibility: Specifically designed for Atlas Copco electric tightening tools or corresponding industrial automation equipment

___________________________________________________________________________________________________________________________

Product Features

• High-Precision Control: Features high accuracy and fast response, capable of meeting the strict quality requirements in industrial assembly processes.
• Compact Structure: The hardware has a compact design, suitable for installation inside control cabinets or industrial equipment, saving space effectively.
• Strong Expandability: Supports multiple communication protocols and has high expandability, applicable to complex industrial tools and multi-task operation scenarios.

___________________________________________________________________________________________________________________________

Structure and Composition

• Main Control Board: Responsible for core motor drive and torque control logic.
• Communication Module: Built-in communication interfaces (such as Profinet, USB, RS232, etc.) for data interaction with upper-level systems or other devices.
• Power Supply Module: Provides stable power required for the drive itself and its control circuit.

___________________________________________________________________________________________________________________________

Application Fields

• Automotive Manufacturing: Chassis assembly, body assembly, etc.
• Electronic Product Assembly: Precision assembly of mobile phones, computers and other electronic products.
• Electrical Equipment Production: High-reliability industrial connection scenarios.
• Traceability System: Assembly lines requiring multi-station process control and traceability.

___________________________________________________________________________________________________________________________

Installation and Maintenance

Installation

Maintenance
