ATLAS PF3107-C-IB2-HW Input/Output Module

The PF3107-C-IB2-HW belongs to the Power Focus 3100 series, designed for medium-power electric tightening systems.

ATLAS PF3107-C-IB2-HW

1. Overview

The PF3107-C-IB2-HW belongs to the Power Focus 3100 series, designed for medium-power electric tightening systems. It is mainly used in high-precision scenarios requiring strict torque control, such as automotive manufacturing, aerospace, and electronic assembly.

_______________________________________________________________________________________________________

2. Specifications

Specification	Description
Model	PF3107-C-IB2-HW
Input Voltage	90-240V AC, 50/60Hz
Output Power	Approx. 300W
Communication Interface	PROFINET (IB)
Tool Compatibility	Tensor 3 to Tensor 7 series (including Tensor 5, 7, etc.)
Control Functions	Torque Control, Angle Control, Combined Control
Data Processing	Supports data recording, curve storage and real-time transmission for each tightening process
Program Capacity	Supports up to 255 tightening programs

_______________________________________________________________________________________________________

3. Product Features

High-Precision Control: Adopts advanced control algorithms to control torque and angle within an extremely narrow error range, ensuring the fastening quality of connectors.
Powerful Data Traceability: Built-in data processing function, key data of each tightening process can be recorded and uploaded to the MES system, facilitating quality traceability.
Multi-Protocol Support: In addition to PROFINET, it usually supports industrial network protocols such as DeviceNet and Ethernet/IP, making it easy to integrate into existing production lines.
Modular Design: Compact structure, easy to install in combination with electric tools or use as an independent control unit.

_______________________________________________________________________________________________________

4. Structure and Composition

Power Supply Module: Responsible for converting industrial power into low-voltage DC power required inside the controller.
Control Core Board: Includes CPU, RAM, ROM and memory for storing tightening programs.
Communication Module: Communication card supporting industrial network protocols such as Profinet, DeviceNet or Ethernet/IP.
I/O Interface Board: Used to connect electric tools, sensors (such as torque sensors, angle sensors) and external devices.
Display and Operation Panel: Some models may be equipped with an LCD display or operation buttons for on-site engineers to set parameters and diagnose faults.

_______________________________________________________________________________________________________

5. Application Fields

Automotive Manufacturing: Tightening of key bolts for engines, gearboxes, chassis and body structural parts.
Aerospace: High-precision assembly of aircraft structural parts and engine components.
Electronic Appliances: High-precision assembly of battery modules, electric drive systems and electronic products.
Heavy Machinery: Structural connection of construction machinery and rail transit equipment.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation Method

The controller usually adopts a compact design, suitable for independent workstations or embedded cabinet installation. Ensure good ventilation during installation to prevent overheating.

Wiring Requirements

When connecting electric tools, strictly follow the wiring diagram in the official manual, especially the wiring of torque sensors and angle sensors, to avoid introducing signal errors.

Maintenance

Regularly check the tightness of connecting cables, remove dust inside the controller, and ensure the cooling fan operates normally. At the same time, it is recommended to update the software regularly to obtain the latest function optimizations and bug fixes.

————————————————————————————————-
