ATLAS PF3009-C-HW
1. Product Overview
The ATLAS PF3009-C-HW is a torque controller belonging to the Tensor S9 series. As the core control unit in the Nutrunner system, it is responsible for executing torque control commands and feeding back real-time status to operators through a display screen or HMI (Human-Machine Interface).
___________________________________________________________________________________________________________________________
2. Key Technical Parameters
|
Parameter Category
|
Specific Value
|
|---|---|
|
Power Supply Requirement
|
90-240 VAC, 50/60 Hz, Single-phase
|
|
Power
|
300W
|
|
Control Functions
|
Supports Torque Control, Angle Control, Composite Control, Program Setting
|
|
Display & Operation
|
Graphical Operation Interface, Supports User Programming
|
|
Weight
|
Approx. 12–16 kg (depending on configuration)
|
|
Communication Interface
|
Supports Industrial Ethernet, Serial Port, I/O Signal Expansion, etc.
|
|
Compatibility
|
Supports ToolsTalk Process Programming and Remote Control System
|
___________________________________________________________________________________________________________________________
3. Product Features
- High-Precision Control: Adopts advanced torque control algorithms, capable of working within a narrow torque window to ensure fastening quality.
- Modular Design: Supports pluggable modules (such as RBU modules), facilitating tool parameter setting, maintenance and upgrade.
- Intelligence: Equipped with torque curve monitoring, data recording and analysis functions, enabling convenient subsequent quality traceability.
- Multi-Language Support: The operation interface usually supports multi-language display, facilitating global use.
- Strong Compatibility: Seamlessly compatible with various Atlas Copco Nutrunner mechanical components (such as PF3007, PF3009 series).
___________________________________________________________________________________________________________________________
4. Structure and Composition
Although the specific internal structure is a core secret, generally speaking, the PF3009-C-HW consists of the following main components:
- Power Supply Module: Responsible for converting AC voltage into DC voltage required by the control circuit.
- Control Unit (CPU): Executes torque control algorithms and processes sensor signals.
- Human-Machine Interface (HMI): Includes LCD display and operation buttons.
- Communication Module: Used for data exchange with upper computer systems (such as PC, PLC).
- Safety and Protection Circuit: Prevents abnormal conditions such as overvoltage, undervoltage and overcurrent.
___________________________________________________________________________________________________________________________
5. Main Application Fields
- Automotive Manufacturing: Engine assembly, body assembly, chassis fastening, etc.
- Aerospace: Airframe structure, engine component assembly.
- Shipbuilding: Bolt fastening of large structural parts.
- Mechanical Manufacturing: Assembly and maintenance of large equipment and molds.
- Energy Industry: Wind turbine blade, generator set assembly.
___________________________________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation Notes
- Power Matching: Ensure that the local power grid voltage matches the rated voltage of the equipment (90-240 VAC).
- Ground Protection: Must be properly grounded during installation to prevent instrument damage caused by leakage.
- Environmental Requirements: The equipment should be installed in a dry environment without corrosive gas, avoiding rainwater exposure.
Maintenance Recommendations
- Regular Calibration: Due to the high precision requirement for torque control, it is recommended to send the equipment back to the manufacturer or authorized service station for torque calibration regularly (e.g., once a year).
- Software Upgrade: Pay attention to the firmware or software upgrades released officially by Atlas Copco to obtain new functions and security patches.
- Cleaning and Maintenance: Keep the equipment vents clean to prevent overheating caused by dust ingress.
- Wiring Inspection: Regularly check the connection status of power cables and communication cables to prevent faults caused by looseness.
————————————————————————————————-
