ATLAS PF3007-C-DN-HW
1. Core Overview
- Full Name: PF3007-C-DN-HW Nutrunner Controller
- Product Positioning: An intelligent tightening controller for the medium power segment, part of the Power Focus 3000 series.
-
Model Interpretation:
Core Functions: It is mainly responsible for driving electric nutrunners, executing precise torque and angle control commands, and conducting data interaction with upper computers (such as PLC, MES).
- PF3007: Indicates the medium power segment (3000 series).
- C: Represents the standard control version (Control).
- DN: Supports DeviceNet communication protocol.
- HW: Hardware version.
___________________________________________________________________________________________________________________________
2. Key Technical Parameters
|
Parameters
|
Specifications/Description
|
|---|---|
|
Power Input
|
AC 100–240V (Global Universal)
|
|
Communication Protocol
|
DeviceNet (Main), some models support Ethernet, RS232/RS485
|
|
Control Functions
|
1. Torque Control: Precise torque output2. Angle Control: Rotation angle control3. Multi-stage Control: Execute different torque/angle in stages
|
|
Safety Detection
|
Thread Slip Detection, Under-torque Detection, Missing Tightening Detection
|
|
Automatic Re-tightening
|
Supports automatic detection and compensation of torque deviation to ensure assembly quality
|
|
Storage Capacity
|
Can store hundreds of different tightening programs (the specific number varies slightly by firmware version)
|
3. Product Features & Advantages
- High Intelligence: Equipped with rich safety detection functions, it can automatically identify assembly errors and take remedies, reducing manual intervention.
- Flexible Communication: Supports DeviceNet protocol, easy to integrate into industrial field bus systems, realizing seamless connection with PLC or robot controllers.
- Reliable Precision: Designed specifically for high-torque segments, it can meet the tightening requirements of key components such as automotive engines and chassis.
- Industrial-grade Design: Suitable for harsh production environments, with high anti-interference ability and stability.
___________________________________________________________________________________________________________________________
4. Structure & Composition
- Control Mainboard: Includes core processor, I/O interface and communication interface.
- Power Drive Module: Responsible for converting power signals into drive current required by electric nutrunners.
- Display/Operation Panel (Optional): Used for on-site parameter setting and fault indication.
- Mounting Bracket: Used for fixing on guide rails or in control cabinets.
___________________________________________________________________________________________________________________________
5. Main Application Fields
- Automotive Manufacturing: Engine assembly, chassis welding, key bolt tightening of body structural parts.
- Construction Machinery: Connection and maintenance of large structural parts.
- Rail Transit: Car body assembly and fixing of key components.
- Aerospace: High-precision assembly (specific model applicability needs to be confirmed according to configuration).
- Heavy Equipment Manufacturing: Scenarios requiring high-torque tightening such as ships and wind power equipment.
————————————————————————————————-
