1. Overview

2. Specifications

3. Product Features

• High Precision: Delivers extremely high torque accuracy and repeatability, ideal for precision assembly applications that demand strict process control.
• Multi-functionality: Integrates advanced features including slip detection, missing tightening protection, automatic re-tightening, and error alarm, effectively preventing production defects caused by operational errors.
• Flexibility: Supports hundreds of tightening programs, enabling quick switching between different product models and adapting to multi-variety, small-batch production modes.
• User-friendly Interface: Equipped with a graphical user interface (G version), facilitating on-site parameter setting, status monitoring, and equipment debugging for operators.

_______________________________________________________________________________________________________

4. Structure and Composition

• Host Unit: Undertakes core control and calculation, processing key data such as torque and angle in real time to ensure the stability and accuracy of the tightening process.
• Display and Keyboard: Used for parameter configuration and status monitoring; the G version features a graphical interface to simplify operation and reduce learning costs.
• Communication Module: Enables seamless integration with PLC, HMI, or upper computer systems (such as Power Focus), realizing centralized control and data management of the entire production line.

_______________________________________________________________________________________________________

5. Application Fields

• Automated Assembly Lines: Applied for precision tightening in robotic or automated workstations, widely used in the assembly process of various industrial products.
• Quality Control: Suitable for the assembly of automotive, aerospace, and electronic products that require strict torque control, helping enterprises meet high-quality production standards.
• Industrial Production: Perfect for assembling components such as machine tools, valves, and frames with medium torque requirements, adapting to a wide range of industrial production scenarios.

_______________________________________________________________________________________________________

6. Installation and Maintenance

• Installation Method: Supports standard industrial control cabinet rail mounting or panel mounting, featuring easy installation and space-saving design.
• Maintenance Recommendations: Regularly inspect communication interfaces to ensure stable connections; clean the display panel to avoid dust interference; ensure good ventilation around the equipment to prevent overheating and extend service life.
• Compatibility: Compatible with Atlas Copco’s Tensor ST, ES, ETX, and other series tools, facilitating the upgrade and transformation of existing production lines and reducing investment costs.
