ATLAS PF3000
1. Product Overview
The ATLAS PF3000 series is a high-precision fastening control system specifically designed for industrial automation tightening applications. Integrating drive, power supply and communication modules, this series of products can achieve precise control of torque and angle, and is widely used in automotive manufacturing, rail transit, energy equipment and other fields.
2. Core Technical Parameters
|
Parameter Category
|
Specific Parameters
|
Description
|
|---|---|---|
|
Model
|
PF3000-F-DN-HW / PF3000-C-DN-HW
|
F: Low power segment (medium torque); C: Medium power segment (high torque)
|
|
Communication Interface
|
DeviceNet (DN)
|
Supports industrial bus communication, facilitating MES system integration
|
|
Power Supply
|
AC 200-240V / 24V DC (depending on version)
|
Adopts industrial-grade standard power supply with high protection level
|
|
Control Precision
|
Torque Precision ±0.5%
|
Adopts high-rigidity control algorithm to ensure torque consistency
|
|
Data Storage
|
Built-in Memory
|
Supports data traceability and process parameter management
|
|
Compatibility
|
Compatible with Atlas Tensor series electric tools (e.g., ST, ES, ETX)
|
Suitable for medium torque assembly tasks
|
3. Product Features
- Industrial-grade Reliability: Adopts high-quality stainless steel material and silent belt drive system, resistant to wind, rain, high and low temperatures, suitable for harsh industrial environments.
- Intelligent Control: Built-in high-precision sensors to achieve closed-loop control of torque and angle with minimal error.
- Easy Integration: Supports DeviceNet communication, which can be easily connected to factory automation systems to achieve data interconnection.
- Modular Design: Hardware versioning (HW) facilitates function expansion according to on-site needs.
4. Structure and Composition
- Control Unit: Integrates CPU, memory and communication interface, responsible for instruction processing and data operation.
- Drive Module: Responsible for motor start-stop, speed regulation and torque output.
- Power Module: Provides stable industrial-grade power input.
- Terminal Blocks: Used to connect electric tools (such as Atlas Tensor series) and sensors.
5. Application Fields
- Automotive Manufacturing: Tightening of key bolts for engines, gearboxes, chassis and body structural parts.
- New Energy Vehicles: High-precision assembly tasks such as power battery modules and electric drive systems.
- Construction Machinery and Rail Transit: High-torque fastening of structural connections, braking systems and suspension components.
- Industrial MES System: Integrated into the manufacturing execution system to achieve production process data traceability.
6. Installation and Maintenance
- Installation: The installation of PF3000 usually needs to be completed by professional electrical engineers. Its compact design is suitable for installation on workstations of production lines.
- Maintenance: Due to the industrial-grade sealed design, daily maintenance mainly includes regular cleaning of heat dissipation ports, checking whether cable connections are loose and updating control software.
- Safety: During installation, ensure that the power supply is well grounded, and the operation panel should be set in a position that is easy to view but not easy to touch by mistake.
————————————————————————————————-
