ATLAS PF300-G-HW
Product Overview
The ATLAS PF300-G-HW is an enhanced-function industrial tightening controller equipped with a DeviceNet communication interface, suitable for medium-sized assembly lines and automated workstations. This controller can control Tensor series electric tools to achieve precise torque, angle control and data traceability, serving as a key execution unit in intelligent manufacturing. It supports torque control, angle control and multi-stage composite tightening control, is compatible with tools such as Tensor ST, ES and ETX, and can store multiple tightening programs to facilitate multi-variety switching. The controller supports communication protocols including DeviceNet, Ethernet, RS232 and I/O, can be set up and monitored through ToolsTalk PF software, and is suitable for control cabinet or workstation integration.
_______________________________________________________________________________________________________
Core Parameters & Technical Specifications
|
Parameters
|
Description
|
|---|---|
|
Communication Interface
|
DeviceNet, Ethernet, RS232, Digital I/O
|
|
Compatible Tools
|
Tensor ST, ES, ETX and other electric tools
|
|
Control Mode
|
Torque Control, Angle Control, Multi-stage/Composite Control
|
|
Process Functions
|
Supports slip/omission/under-torque detection and automatic re-tightening
|
|
Program Capacity
|
Supports storage and switching of hundreds of tightening programs
|
|
Installation Method
|
Standard industrial rail mounting or control cabinet embedded mounting
|
_______________________________________________________________________________________________________
Product Features
- High-Precision Control: Configurable via ToolsTalk PF software, enabling high-precision torque and angle control to ensure assembly accuracy.
- Powerful Communication Capability: Built-in DeviceNet interface, supporting seamless integration with PLC and MES systems to realize data traceability and process management.
- Multi-Function Integration: Supports slip, omission and under-torque detection as well as automatic re-tightening, effectively guaranteeing assembly quality.
- Flexible Installation: Compatible with standard industrial rail mounting, easy to integrate into existing production lines.
_______________________________________________________________________________________________________
Structure & Composition
- Control Host: The core control unit, including CPU and display screen, responsible for overall operation control.
- Communication Module: Responsible for the communication of protocols such as DeviceNet, ensuring stable data transmission.
- Power Module: Provides AC 100–240V power input to supply power for the entire controller.
- Tool Interface: The interface for connecting tensioning tools (such as Tensor series), enabling signal transmission between the controller and tools.
_______________________________________________________________________________________________________
Application Fields
- Automotive Manufacturing: Tightening of key bolts for engines, gearboxes, chassis and body structural parts.
- New Energy Vehicles & Battery Manufacturing: High-precision assembly tasks such as power battery modules, electric drive systems and electronic control boxes.
- Construction Machinery & Rail Transit: High-torque fastening of structural part connections, braking systems and suspension components.
- Industrial Automation: Cooperating with robot assembly to realize automatic linkage and improve production efficiency.
————————————————————————————————-
