ATLAS PF-4000-C-DN-HW
Product Overview
The PF-4000-C-DN-HW is a high-performance tightening controller specifically designed for the automated process control of electric torque tools. It communicates with upper computers such as PLCs through the DeviceNet (DN) industrial bus interface, supporting multiple tightening modes including torque control, angle control, and composite control. While ensuring tightening quality, the controller provides complete data traceability functions, facilitating production statistics and quality analysis.
_______________________________________________________________________________________________________
Key Specifications
|
Parameter
|
Specification
|
|---|---|
|
Product Model
|
PF-4000-C-DN-HW
|
|
Communication Interface
|
DeviceNet (DN)
|
|
Power Supply
|
AC 100–240V, 50/60Hz
|
|
Supported Tools
|
Compatible with Tensor series electric torque tools (e.g., Tensor ST, Tensor DS, etc.)
|
|
Control Modes
|
Torque Control, Angle Control, Composite Control, Slip/Loss/Under-torque Detection
|
|
Software Platform
|
Parameter setting and program writing via Power Focus software
|
|
Dimensions
|
319 mm (L) × 173 mm (W) × 415 mm (H)
|
|
Weight
|
Approx. 26.45 lbs (Approx. 12.19 kg)
|
_______________________________________________________________________________________________________
Product Features
- High-Precision Control: Supports high-precision tightening control at the 0.1% level to ensure the fastening quality of connectors.
- Multifunctional Modes: Integrates advanced functions such as torque control, angle control, slip/loss detection, enabling automatic re-tightening and data recording.
- Powerful Data Traceability: Real-time collection of tightening data, supporting storage of hundreds of sets of tightening programs for easy traceability and quality analysis.
- Industrial-Grade Communication: Equipped with a DeviceNet interface for easy integration into industrial automation systems.
_______________________________________________________________________________________________________
Structure and Composition
- Control Host: The core computing unit responsible for executing control algorithms and data processing.
- Communication Interface Module: Supports DeviceNet communication to connect PLCs and upper computers.
- Power Supply Module: Provides stable working power.
- Software Platform: Parameter setting, program writing, and data monitoring via Power Focus software.
_______________________________________________________________________________________________________
Application Fields
- Automotive Manufacturing: Automated assembly of engine, body, chassis and other components.
- Aerospace: Precision assembly of aero-engines and airframe structural parts.
- Railway: Assembly of train bodies and chassis.
- Other High-End Manufacturing: Fields such as high-precision machinery and medical equipment.
_______________________________________________________________________________________________________
Installation and Maintenance
- Installation Method: Standard industrial rail mounting or control cabinet embedded mounting.
- Maintenance Requirements: It is recommended to use in a dust-free and dry environment, and perform regular system inspection and calibration to ensure tightening precision.
- After-Sales Service: It is recommended to contact official authorized Atlas Copco distributors for installation, commissioning and maintenance services.
————————————————————————————————-
