Efficiency:98%

Continuous Current (rms):10.6 A

Continuous Current (0-peak):15.0 A

PWM Frequency:4 kHz

Bandwidth Velocity Loop:500 Hz

Internal Shunt Continuous Power:N/A

Internal Shunt Peak Power:N/A

Nominal Input Voltage:325 V DC

Shunt On:N/A

Module Type:Axis Module

Series:Kinetix 6000

Weight:5.1 pounds (2.31 kg)

Voltage Class:400V AC

Continuous Output Current:10.3 A

Peak Output Current:14.6 A

Voltage:400/460 V

    The Allen-Bradley AB 2094-AM02-S Kinetix Axis Module is a cornerstone of advanced motion control systems, offering unparalleled efficiency with a continuous current of 10.6 A at root mean square (rms), and a peak current of 15.0 A, ensuring seamless operation across a wide range of industrial environments.

    Designed with a bandwidth velocity loop of 500 Hz and a robust 4 kHz Pulse Width Modulation (PWM) frequency, this module ensures precise and responsive control, making it ideal for applications requiring high performance and accuracy.

    Built to withstand the rigors of industrial conditions, the AB 2094-AM02-S features an internal shunt that enhances its power handling capabilities, supporting a nominal input voltage of 325 VDC, making it a versatile choice for various industrial setups.

    Its lightweight design, weighing just 2.31 kilograms, facilitates easy integration and deployment in tight spaces without compromising performance. The module’s comprehensive array of connectors ensures seamless connection to a wide range of equipment, streamlining setup and maintenance.

    Equipped with the latest technology for enhanced safety and reliability, the Allen-Bradley AB 2094-AM02-S Kinetix Axis Module is not just a component; it’s a solution that elevates your motion control systems, delivering superior performance and efficiency.
