Brand:Allen-Bradley

Model:1756-IR12

Module Type:Temperature Input Module

Application Range:-40°F to 158°F (-40°C to 70°C)

Resolution:0.1°C (0.1°F)

Accuracy:±0.5°C (±0.9°F) at 25°C (77°F)

Input Range:4-20 mA, 0-10 V, Thermocouples (K, J, E, T, N, R, S)

Environmental Rating:IP20, 5-95% RH non-condensing

Power Consumption:≤ 2.5 W

Communication Protocol:ControlNet, DeviceNet, Ethernet/IP

Number of Inputs:12

Installation:Panel-Mount, DIN Rail-Mount

    The Allen-Bradley 1756-IR12 ControlLogix Temperature Input Module is engineered for demanding industrial environments where precise temperature monitoring is critical. This high-performance module offers 12 channels capable of measuring temperatures from -40°F to +158°F (-40°C to +76°C) with an exceptional accuracy of +/- 0.25% of full scale.

    Designed for ControlLogix systems, this module ensures seamless integration with existing Allen-Bradley automation solutions, providing users with unparalleled control and flexibility in managing their industrial processes.

    Equipped with advanced communication protocols like ControlNet, the module facilitates efficient data exchange within complex industrial networks, enabling real-time monitoring and control.

    Crafted with a robust IP20 enclosure, it withstands harsh environmental conditions, ensuring reliable operation in industrial settings with wide temperature ranges and varying humidity levels.

    The low power consumption of less than 1.5W makes it an energy-efficient choice for long-term monitoring applications without compromising on performance. Its compact design optimizes space utilization, making it suitable for various industrial layouts.
