Model Type:Discrete Input Module

High Capacity:16-point input capacity

Manufacturer:Allen Bradley

Communication Cable:Standard shielded twisted pair

Temperature Rating:-40°C to +70°C

Power Supply:24V DC

Isolation:3000V DC

Environmental Conditions:Non-condensing relative humidity

Vibration Resistance:10G

Shock Resistance:15G

Enclosure:IP20 Open Type

Mounting:DIN Rail or Panel Mount

Operating Voltage:24V DC

Current per Point:Max. 500mA

Power Consumption:1W

Communication Speed:10/100 Mbps Ethernet/IP

Communication Protocol:EtherNet/IP

Interface:Ethernet

    The Allen Bradley 1756-IB16 Input Module is designed for high-reliability applications, offering a robust solution for monitoring and controlling industrial processes. It provides 16 discrete inputs, ideal for detecting various states in machinery or production lines.

    Each input channel features advanced isolation technology, ensuring safety and preventing signal interference. The module supports Modbus/TCP communication protocol, enabling seamless data exchange with Allen-Bradley ControlLogix PLCs and other compatible devices.

    With an operating temperature range of -40°C to 70°C, this input module is suitable for harsh industrial environments. Its compact design allows easy installation on DIN rails or panels, minimizing space requirements on the factory floor.

    For enhanced system efficiency, the Allen Bradley 1756-IB16 includes advanced diagnostics capabilities, which continuously monitor the health of the inputs, alerting operators to potential issues before they disrupt production.

    The module’s comprehensive feature set, combined with its durability and ease of integration, makes it an indispensable component in modern industrial automation systems. Whether you are upgrading existing infrastructure or building new facilities, the Allen Bradley 1756-IB16 ensures optimal performance and reliability in your operations.
