Model Type:EtherNet/IP Bridge Module

Manufacturer:Allen-Bradley

Model Number:1756-ENBT

Communication Speed:10/100 Mbps

Communication Protocol:Ethernet/IP

Enclosure Type:Open Type

Temperature Rating:0 – 60 °C

Power Supply:3 MA at 24 VDC

Environmental Conditions:5 – 95% non-condensing relative humidity

Vibration Resistance:2 G

Shock Resistance:30 G

Connection Cables:802.3 compliant shielded or unshielded twisted pair

Power Dissipation:5.1 W

Isolation:30 V continuous

    The Allen-Bradley 1756-ENBT Communication Module is specifically engineered for high-speed, reliable data transmission in industrial automation environments. Its compatibility with ControlLogix systems ensures seamless integration and enhanced efficiency.

    With its robust design, the 1756-ENBT is built to withstand demanding industrial conditions, offering continuous isolation up to 30V and exceptional vibration and shock resistance.

    Featuring an open type enclosure, this module provides easy access for installation and maintenance, while its Ethernet/IP bridge capability ensures secure and fast communication networks, crucial for complex industrial operations.

    Equipped with a power supply of 3 MA at 24 VDC, it ensures consistent performance under varying operational demands. The module’s temperature rating of 0 – 60 DEG C allows for reliable operation in a wide range of environments, making it suitable for most industrial settings.

    Optimized for both shielded and unshielded twisted pair cables, the 1756-ENBT ensures compatibility with a variety of cabling solutions, enhancing flexibility in network setup. This makes it an ideal choice for optimizing industrial automation networks and improving overall productivity.
