Manufacturer:Allen Bradley

Model Number:1747-L542

Type:SLC 5/04 Modular Processor Unit

Memory:32 KB

Backup:Flash

Interface:DH+ And RS-232 Ports

Mounting:Chassis

Output:Backplane: 1 MA At 5 VDC

Response Time:Typical Scan: 0.9 MS/Kword

Bit Execution:0.37 MIC-SEC

I/O Scan:0.255 MS

Programming Devices:RSLogix 5000 Software

Enclosure:Open Type

Display:Status LEDs

Dimensions:Length: 145 MM, Width: 35 MM, Height: 142 MM

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95% Non-Condensing Humidity

Shock:30 G

Vibration:0.015 IN (Displacement), 2.5 G (Acceleration)

Certifications:[“GOST certified”,”KC certified”,”MARINE certified”,”UL listed”,”cUL listed”,”CE marked”,”C-Tick certified”]

    The Allen Bradley 1747-L542 Modular Processor Unit is a high-performance PLC system designed for industrial automation. With its advanced instruction set and robust design, it offers unparalleled reliability and efficiency for a wide range of applications.

    This modular processor unit supports up to 4096 discrete inputs and outputs, along with 480 local analog I/O channels, making it ideal for complex industrial control systems. The system’s compatibility with DH+ and RS-232 interfaces ensures seamless integration with existing industrial networks.

    The 1747-L542 is equipped with a 32 KB memory and flash backup, ensuring data integrity and ease of maintenance. The open-type enclosure with status LEDs provides clear visibility into system operation and diagnostics.

    Designed for harsh industrial environments, the 1747-L542 can withstand shock up to 30 G and vibration up to 2.5 G (acceleration). Its operating temperature range of 0°C to 60°C and humidity tolerance from 5% to 95% non-condensing make it suitable for various environmental conditions.

    Certified by international standards such as GOST, KC, MARINE, UL, cUL, CE, and C-Tick, the 1747-L542 meets stringent safety and performance requirements, providing peace of mind for industrial operations.
