Allen-Bradley 136-BX040-AN-E
1. Overview
The Allen‑Bradley 136‑BX040‑AN‑E is a member of the SV+ (Sensorless Vector Plus) series from Rockwell Automation. Designed for medium‑to‑high power industrial applications, this 40 HP (30 kW) drive delivers precise speed and torque control for a wide range of machinery, including machine tools, packaging equipment, textile machines, mining systems, and other automation solutions requiring reliable motion control.
____________________________________________________________________________________________
2. Key Specifications
|
Parameter
|
Specification
|
|---|---|
|
Power Rating
|
40 HP (30 kW)
|
|
Motor Type
|
Three‑phase AC induction motor
|
|
Input Voltage
|
460 V AC
|
|
Output Frequency
|
0 – 400 Hz (other ranges available)
|
|
Control Method
|
Sensorless Vector (SV)
|
|
Efficiency
|
High efficiency, compliant with IEC/EN 61800‑3
|
|
Operating Temperature
|
-20°C to +50°C (depending on mounting)
|
|
Protection Class
|
NEMA 4 or IP20
|
|
Communication
|
EtherNet/IP, DH+ (Profibus/Profinet optional)
|
|
Dimensions
|
7.75 in (196.9 mm) H × 6.75 in (171.5 mm) W × 1 in (25.4 mm) D
|
3. Product Features
- Sensorless Vector Control: Achieves accurate speed and torque regulation without physical feedback devices, reducing system cost and complexity.
- Energy Efficient: Advanced power electronics minimize energy loss and lower operational costs.
- Flexible Programming: Seamlessly integrates with Allen‑Bradley PLCs via Ladder Logic and EtherNet/IP for easy system configuration.
- Rugged Design: Built to withstand harsh industrial environments with strong resistance to electrical noise and mechanical stress.
____________________________________________________________________________________________
4. Construction and Components
- Power Module: Converts incoming AC power to adjustable voltage and frequency using IGBT or MOSFET technology.
- Control Module: Features a high‑performance microprocessor or DSP to execute vector control algorithms and manage I/O signals.
- Communication Interfaces: Provides EtherNet/IP, DH+, and serial connectivity for remote monitoring and configuration.
- Cooling System: Equipped with fans and heat sinks to ensure stable operation under heavy loads.
____________________________________________________________________________________________
5. Typical Applications
- Machine Tools: Spindle drives for lathes, milling machines, and other equipment requiring precise torque control.
- Packaging Machinery: Synchronized control for winding, conveying, and packaging processes.
- Textile Equipment: High‑efficiency and accurate speed control for textile manufacturing.
- Fans and Pumps: Variable speed operation to match load requirements and reduce energy consumption.
____________________________________________________________________________________________
6. Installation and Maintenance
- Space Requirements: Allow at least 6 inches (152.4 mm) of clearance on all sides for proper ventilation and maintenance.
- Electrical Wiring: Follow local electrical codes (e.g., GB 50303) to ensure secure connections and minimize electrical interference.
- Cooling Maintenance: Regularly clean air inlets and outlets, and check fan operation to maintain optimal heat dissipation.
- Parameter Backup: Before commissioning, back up original parameters via EtherNet/IP to prevent startup issues after adjustments.
____________________________________________________________________________________________
7. Common Issues and Troubleshooting
- Inaccurate rotor position detection: Ensure a stable three‑phase power supply and avoid voltage imbalance or harmonic distortion.
- Frequent overcurrent trips: Check for motor overload, rotor jamming, or excessive mechanical load.
- Communication failures: Verify IP address settings, use shielded Ethernet cables, and confirm correct node configuration in the PLC program
————————————————————————————————-
