The Allen‑Bradley 1336S‑BRF30 is a high‑performance variable frequency drive (VFD) from Rockwell Automation, designed to deliver reliable and precise motor control across a wide range of industrial applications. Built on Allen‑Bradley’s advanced POWERCORE™ platform, this VFD offers exceptional flexibility, scalability, and performance—from basic speed control to complex vector control tasks.

____________________________________________________________________________________________

1. Key Specifications

• Power Range: 3 HP (2.2 kW) up to 30 HP (22.4 kW), suitable for most industrial motors.
• Voltage Options: Multiple voltage ratings available, including 480 VAC (US/EU standard) and 200–240 VAC (Japan/Asia standard).
• Frequency Range: 0–400 Hz for full‑range speed control.
• Control Modes: V/Hz control, vector control, and advanced functions such as multi‑axis synchronization.
• Protection Features: Overvoltage, undervoltage, overcurrent, phase loss, overtemperature, and short‑circuit protection.

____________________________________________________________________________________________

2. Product Features

• Compact Design: Space‑saving chassis ideal for DIN‑rail or panel mounting.
• Modular Construction: Separated power, control, and I/O modules for easy maintenance and upgrades.
• Flexible I/O: Supports discrete, analog, and optional communication modules (including data logging).
• User‑Friendly Interface: LCD display with clear status indicators and fault codes for quick troubleshooting.
• Harsh Environment Ready: Some models feature a corrosion‑resistant coating (designated by “S”) for use in humid or corrosive conditions.

____________________________________________________________________________________________

3. Structure & Components

• Main Unit: Contains the power circuit (IGBTs) and main controller for motor driving and signal processing.
• Mounting Bracket: Secures the VFD with four bottom mounting holes.
• I/O Modules: Customizable input/output modules for digital, analog, and fieldbus communication.
• Accessories: Cooling fans, terminal blocks, transformers, and other optional components.

____________________________________________________________________________________________

4. Application Fields

• Food & Beverage: Precision control for filling machines and packaging lines.
• Chemical & Pharmaceutical: Variable‑speed drives for mixers, conveyors, and pumps.
• Mining & Metallurgy: Heavy‑duty applications such as ore conveyors, rolling mills, and cranes.
• Paper & Textile: Speed regulation for paper machines and textile equipment.
• Automated Production Lines: Robotic systems, assembly lines, and sorting equipment.

____________________________________________________________________________________________

5. Installation & Maintenance

• Installation: DIN‑rail or wall mounting. Ensure proper ventilation with a recommended 6–8 inches of clearance for heat dissipation.
• Wiring: Follow correct phase sequence for power connections; I/O wiring should be configured based on your control system requirements.
• Maintenance: Common issues involve power modules (IGBTs) or capacitors. Use the LCD‑displayed fault codes to quickly identify problems such as overcurrent or overvoltage.
