1. Overview

2. Specifications

• Power: Typically 30 HP (approximately 22.4 kW). The specific power rating may vary slightly depending on the region and voltage specifications.
• Voltage Rating: Supports 380-480 VAC or 513-620 VDC, compatible with three-phase AC power supplies.
• Frequency Range: Usually 0-400 Hz, meeting most variable frequency speed regulation requirements.
• Control Methods: Equipped with V/Hz (Voltage/Frequency) control mode, and supports advanced control strategies such as Sensorless Vector Drive.

3. Product Features

• High-Performance Motor Control: Adopts advanced vector control technology to provide efficient motor speed regulation.
• Modular Design: Supports different language modules (EN for English) and control interfaces, facilitating customization according to requirements.
• Industrial-Grade Reliability: Designed in accordance with Rockwell Automation’s industrial standards, featuring high durability and anti-interference capability.

4. Structure and Composition

• Housing (B060): Provides physical protection and heat dissipation for the product.
• Language Module (EN): Used to set the operating language.
• Control Interface (L6): Supports the connection of specific types of PLCs or controllers.
• Programming Controller (HA): A human-machine interface module for local setting and parameter adjustment.
• Communication Card (GM): Optional, used to realize network communication with other industrial equipment.

5. Application Areas

• Machining: Such as CNC machine tools like lathes and milling machines.
• Packaging Industry: Used to control equipment such as packaging machines and conveyors.
• Injection Molding: Controls the motion axes of injection molding machines.
• Other General Motor Drives: Such as fans, water pumps, elevators, etc.

6. Installation and Maintenance

Installation

Maintenance
