Allen-Bradley 1336S-BRF100-AA

1. Basic Overview

2. Key Parameters and Technical Specifications

• Input Voltage: Supports 115VAC/230VAC (single‑phase) or 380–480VAC (three‑phase), depending on the specific configuration.
• Power Range: From 0.25 HP (0.19 kW) up to 30 HP (22.37 kW), with different models such as the 1336S‑BRF10‑AA and 1336S‑BRF30‑AA corresponding to different power levels.
• Motor Type: Compatible with single‑phase motors (e.g., 115VAC) and three‑phase motors.
• Output Frequency: 0.1 Hz to 60 Hz as standard; some models may support higher frequencies.
• Overload Capacity: Typically 150% (varies by power rating).
• Control Modes: Includes V/Hz control, vector control (for applicable VFD versions), and multiple torque modes such as constant torque and constant power.

___________

3. Product Features

• Industrial‑Grade Durability: Built to withstand harsh industrial environments with reliable performance.
• Comprehensive Protection: Includes overload, overcurrent, overvoltage, undervoltage, overheating, and ground fault protection.
• Easy Integration: Seamlessly connects with Rockwell Automation Logix‑series PLCs (ControlLogix, CompactLogix) and supports industrial protocols such as EtherNet/IP.
• Energy Efficiency: Uses VFD technology to adjust motor speed based on load, reducing energy consumption.

__________

4. Structure and Components

• Power Module: Contains power semiconductors (e.g., IGBTs), cooling fans, and power conversion circuitry.
• Control Module: Features a microprocessor, communication ports (EtherNet/IP, DeviceNet), and I/O interfaces.
• Motor Terminals: For connecting motor power cables.
• Input Terminals: For external sensors (e.g., potentiometers, thermal relays) or PLC control signals.

___________

5. Application Areas

• Manufacturing: Used to control conveyors, fans, pumps, compressors, and other machinery.
• Processing Industries: Provides spindle control for CNC machines such as lathes, milling machines, and drill presses.
• Food & Pharmaceutical: Suitable for hygienic or explosion‑proof equipment in critical process control.
• Building Facilities: Controls fans and pumps in HVAC systems.

___________

6. Installation and Maintenance

Installation

• Environment: Install in a well‑ventilated, dry area free from corrosive gases. Avoid direct sunlight and high‑temperature heat sources.
• Wiring: Follow the official wiring diagrams for power, ground, control signals, and motor connections.
• Heat Dissipation: Ensure adequate clearance (typically around 6 inches) for proper cooling.

Maintenance

• Regular Checks: Monitor input voltage, output current, and operating temperature.
• Troubleshooting: LED indicators or an LCD display provide fault codes that can be cross‑referenced with the manual to identify issues such as overloads, ground faults, or communication errors.
• Software Updates: Parameters and firmware can be adjusted or upgraded using Rockwell tools such as RSLogix or Studio 5000.

————————————————————————————————-
