Allen-Bradley 1336S-B007-AN

1. Overview

2. Specifications

• Rated Power: 0.75 kW (approximately 1 HP)
• Rated Output Current: 5.5 A
• Input Voltage: 200–240V AC (single‑phase)
• Output Voltage: 0V – 240V AC
• Frequency Range: 0.5 Hz – 150 Hz
• Operating Temperature: -10°C to +40°C
• Storage Temperature: -20°C to +60°C
• Dimensions: Approximately 230mm x 130mm x 45mm
• Weight: Approximately 2.5 kg

_____________________

3. Key Features

• Compact Modular Design: Compared to traditional bulky drives, the 1336 Series uses a modular structure that is smaller, lighter, and easier to install and maintain.
• Multi‑Language / Protocol Support: Built‑in language modules (such as AN, AA) and compatibility with protocols like Modbus RTU and PROFIBUS DP enable seamless integration with PLCs and host systems.
• Intelligent Parameter Tuning: Offers extensive parameter options and supports standard motor profiles (NEMA, IEC), allowing engineers to configure quickly.
• High Efficiency & Low Harmonics: Advanced vector control technology delivers high power factor and low harmonic distortion, meeting energy‑saving standards.
• Comprehensive Protection: Includes overcurrent, overvoltage, overtemperature, and other protection mechanisms to ensure safe operation of motors and equipment.

_________

4. Structure & Components

• Power Supply Module: Converts input voltage to internal working voltage and provides DC power to the inverter bridge.
• Power Module: Consists of IGBT or MOSFET semiconductors that form the inverter bridge and directly drive the motor.
• Control Unit: Features a built‑in microprocessor that runs control algorithms such as V/Hz and vector control.
• Communication Interfaces: Equipped with RS485, Ethernet, and optional protocol modules (AN, AA).
• Display & Keypad: Includes an LCD screen and keyboard for parameter setup, fault diagnosis, and status monitoring.

__________

5. Applications

• Industrial Automation: Commonly integrated with PLC systems to drive conveyors, pumps, fans, compressors, and other machinery.
• Process Control: Used in chemical, pharmaceutical, and food industries for fluid transfer and mixing control.
• Energy Management: Applied in high‑efficiency pump and fan systems to reduce energy consumption.
• Specialized Applications: Its precise torque control makes it suitable for textiles, packaging, and other industries requiring high‑accuracy speed regulation.

————————————————————————————————-
