Allen-Bradley 1336E-B020-AA
1. Overview
The Allen-Bradley 1336E-B020-AA belongs to the IMPACT Series B of drives. Engineered to operate within the input voltage range of 380-480V AC, it is well-suited for a wide array of industrial drive applications, including pumps, fans, conveyors, and ventilators.
_____________________________________________________________________________
2. Specifications
|
Specification
|
Detailed Value/Description
|
Notes
|
|---|---|---|
|
Series
|
1336E (Series B)
|
Medium-power drive
|
|
Model
|
B020
|
Indicates power rating
|
|
Power Range
|
27.2 kW (approx. 36.5 HP)
|
Standard rated power for this model
|
|
Input Voltage
|
380 – 480 VAC (3-phase)
|
Complies with industrial power grid standard voltage
|
|
Rated Current
|
34 A (Maximum)
|
Current requirement at rated power
|
|
Rated Torque
|
20 kW (approx. 30 HP)
|
Maximum mechanical power provided by the drive
|
|
Rated Speed
|
3000 RPM
|
Typical motor speed
|
|
Frequency Range
|
0 – 400 Hz
|
Supports wide frequency range speed regulation
|
|
Efficiency
|
Up to 96% (depending on load conditions)
|
High efficiency, reducing energy consumption
|
|
Enclosure Type
|
NEMA Type 1 (IP20) (Open Type)
|
Suitable for non-extreme environments
|
|
Language Module
|
EN (English)
|
Multi-language support option
|
|
Optional Modules
|
L Option, Human Interface Module (HIM), Communication Cards (RS-232/485)
|
Supports multiple extended functions
|
|
Cooling Method
|
Forced Air Cooling
|
Equipped with internal fan for cooling
|
|
Temperature Range
|
-20°C to 40°C (Ambient Temperature)
|
Suitable for general industrial environments
|
_____________________________________________________________________________
3. Key Features
- Multi-language Support: This model is equipped with a language module (EN), supporting an English operation interface for convenient operation.
- Rich Optional Modules: Supports L Option board (providing multiple contact/level input and output), Human Interface Module (HIM), and communication cards (RS-232, RS-485, DF1, etc.) to meet diverse application needs.
- High Efficiency: Features high efficiency under both full load and partial load conditions, effectively reducing energy consumption and operational costs.
- Advanced Fault Diagnosis: Comes with self-test function and detailed fault code display, facilitating quick maintenance and troubleshooting to minimize downtime.
_____________________________________________________________________________
4. Structure and Components
- Main Control Board: The core control unit responsible for closed-loop speed control, ensuring precise and stable drive performance.
- Power Module: Includes Gate Driver board and power semiconductors (IGBTs), which convert control signals into motor power for reliable drive operation.
- Human Interface Module (HIM): Provides a display and key operation interface, usually integrated into the front panel for easy parameter setting and status monitoring.
- L Option Board: Offers additional control inputs (such as contacts, analog inputs) to expand the drive’s control capabilities.
- Cooling Fan: Designed for heat dissipation, ensuring the drive operates within the safe temperature range.
_____________________________________________________________________________
5. Application Areas
- Industrial Automation: General-purpose AC motor drive control, widely used in various industrial production lines.
- Pump and Fan Control: Fluid systems requiring variable frequency speed regulation, such as water supply and ventilation systems.
- Conveyor Systems: Logistics systems that demand precise speed control to ensure smooth and efficient material transportation.
- Packaging Machinery: Industrial equipment requiring high efficiency and low noise, improving packaging quality and production efficiency.
- Building Facilities: Fan drives in HVAC (Heating, Ventilation, and Air Conditioning) systems, optimizing energy efficiency of building climate control.
————————————————————————————————-
