Allen-Bradley 1336-VT-B125P-E
1. Overview
The Allen-Bradley 1336-VT-B125P-E is part of the Allen-Bradley (Rockwell Automation) 1336 series variable frequency drives. This series is renowned for its high energy efficiency, advanced control algorithms, and reliable performance.
Core Function: Supplies variable-frequency AC power to motors, regulating motor speed, acceleration/deceleration time, and torque.
Technical Characteristics: Typically integrates Sensorless Vector or current-based Vector Control technology, enabling high-performance motor control without the need for rotor position sensors.
___________________________________________________________________________________________________________________________
2. Technical Specifications
- Rated Power: 125 HP (approximately 93 kW)
- Rated Voltage: Usually 460V AC or 480V AC, the standard voltage for North American industrial motors
- Output Current: Approximately 180 A (calculated based on 125 HP power)
- Rated Frequency: 50/60 Hz
- Frame Size: Typically M3 or M4 frame, suitable for installation in industrial distribution cabinets
- Control Method: Field-Oriented Control (FOC) or Sensorless Vector Control (SVV)
- Efficiency Class: Usually meets or exceeds IE3 energy efficiency standards (high-efficiency inverter)
- Environmental Adaptability: Supports NEMA Type 1 (indoor) or Type 4 (enclosure protection) installation
___________________________________________________________________________________________________________________________
3. Features
- Advanced Control Algorithms: Supports high-precision motor speed and torque control
- Energy Saving: Significantly reduces energy consumption by adjusting motor speed to match load requirements
- Compact Design: Adopts a modular design for easy installation and maintenance
- Remote Programming Capability: Supports remote parameter programming and monitoring, usually via Modbus or Ethernet/IP communication protocols
___________________________________________________________________________________________________________________________
4. Structure & Components
- Power Module: Contains IGBT (Insulated Gate Bipolar Transistor) power semiconductors for fast switching of motor current
- Control Board: Includes a DSP or microprocessor to execute control algorithms and communication functions
- Heat Dissipation System: Built-in fans or heat sinks for heat dissipation
- Electrical Interfaces: The input terminal connects to the power grid, the output terminal connects to the motor, and it is equipped with various control signal input/output ports
___________________________________________________________________________________________________________________________
5. Applications
- Manufacturing Industry: Conveyors, presses, and injection molding machines in automotive, packaging, and metal processing
- Energy & Petrochemical Industry: Speed regulation of pumps, fans, and compressors
- Building Systems: Large fans and pumps in HVAC (Heating, Ventilation, and Air Conditioning) systems
___________________________________________________________________________________________________________________________
6. Other Information
Compatibility
This drive can be seamlessly integrated with Allen-Bradley PLCs (such as ControlLogix, CompactLogix) via Ethernet/IP or Modbus communication.
Safety Standards
Complies with international safety and Electromagnetic Compatibility (EMC) standards and supports safe braking functions.
————————————————————————————————-
Main brand
ABB Allen-Bradley Alstom Bently Emerson Foxboro
GE MOOG Schneider Woodward HIMA Honeywel Triconex & more
Contact our professional team today for customized solutions to meet your electrical component needs.
📧 x13806028623@gmail.com / johnedward.zch@gmail.com
📞 +86 18250705533（Whatsapp）丨Sales Manager : Jinny/John
