Allen-Bradley 1336-SN-SP7A Drive Base

The 1336-SN-SP7A is a drive base for the 1336 series inverters. Core Function: Provides physical support and enclosure protection for the drive, and connects the main circuit boards inside the drive. Versatility: Compatible with multiple drive models (such as 1336 Plus, Plus II, Impact, Force, etc.), it is an indispensable hardware foundation in the inverter system.

Allen-Bradley 1336-SN-SP7A

1. Overview

The 1336-SN-SP7A is a drive base for the 1336 series inverters.

Core Function: Provides physical support and enclosure protection for the drive, and connects the main circuit boards inside the drive.

Versatility: Compatible with multiple drive models (such as 1336 Plus, Plus II, Impact, Force, etc.), it is an indispensable hardware foundation in the inverter system.

_____________________________________________________________________________

2. Specifications

Mounting Hole Spacing: Usually 450mm or 500mm.

Material: High-strength steel or alloy with excellent protection performance (IP40/IP65).

Weight: Approximately 1.5kg – 3kg.

Compatibility: Compatible with all 1336 series inverter hosts equipped with the same interface.

_____________________________________________________________________________

3. Product Features

High-Strength Protection: Adopts a metal enclosure with dustproof, waterproof (IP40/IP65) and impact-resistant functions.

Easy Installation: Compact structural design, offering multiple installation methods (vertical/horizontal) and standardized bolt holes.

Excellent Heat Dissipation: The metal material helps dissipate heat inside the drive.

Modular Design: Can be freely combined with various option boards (such as input/output option boards).

_____________________________________________________________________________

4. Structure and Composition

Enclosure: Metal protective shell, usually equipped with screws or fasteners to protect internal circuits.

Mounting Holes: Reserved bolt holes for easy fixing.

Terminal Block: Connects the power cables and control cables of the drive.

Connection Interface: Used to connect the internal host PCB board.

_____________________________________________________________________________

5. Application Fields

As a hardware component, the 1336-SN-SP7A is suitable for all scenarios where 1336 series inverters are installed:

Industrial Automation: Machinery manufacturing, conveyor lines, automated assembly.

Packaging and Printing: Packaging machinery, printing machines, coding machines.

Heating, Ventilation and Air Conditioning (HVAC): HVAC fans, pump control.

Water Treatment: Water pumps, wastewater treatment equipment.

_____________________________________________________________________________

6. Installation and Maintenance

Installation Methods:

Fixing: Use bolts to fix the base on the rack or base.

Wiring: Connect the power cables, ground wires and control cables to the terminal block.

Combination: Install option boards (such as 1336-L4 A-B input option board) on the base.

Maintenance Points:

Moisture and Dust Prevention: Regularly check whether the protective pad is intact to prevent moisture intrusion.

Anti-Corrosion Inspection: Check if the screws are loose or corroded.

Cable Management: Ensure the wiring is neat and avoid tension.

————————————————————————————————-
