Allen-Bradley 1336-SCR-SP13A
1. Overview
PowerFlex 1336-SCR-SP13A is a programmable AC drive (frequency converter) manufactured by Allen-Bradley, a brand under Rockwell Automation.
Positioning: A medium-to-high power industrial frequency converter widely used in general mechanical transmission, precision machine tools, textile machinery, plastic machinery and other fields.
Core Functions: Provides motor starting, speed regulation, reverse rotation and braking control, equipped with multiple vector control modes, and supports comprehensive network communication and remote monitoring.
___________________________________________________________________________________________
2. Parameters
The PowerFlex 1336 series features complete parameterization capabilities, with main parameters including:
Basic Settings: Motor rated power (HP/kW), rated current, rated voltage (three-phase/single-phase), and operating frequency range.
Motor Control Modes: V/F control, sensorless vector control (V/Hz), sensor vector control (SV), and direct torque control (DTC) mode.
Control Logic: 90 user parameters (71 of which are accessible via the panel), including start/stop logic, braking parameters, overload protection settings, and PID parameters.
Communication Interfaces: Supports industrial fieldbus protocols such as EtherNet/IP, DH+, DH-485, and Modbus.
___________________________________________________________________________________________
3. Product Features
Energy Efficiency: Adopts advanced power electronics technology to provide high power factor and low harmonic distortion.
User-Friendly: Consistent parameter structure, consistent operation across models, intuitive panel operation, and support for graphical parameter editing.
Safety and Reliability: Built-in multiple safety functions, including overload protection, short-circuit protection, ground fault monitoring, and thermal protection.
Powerful Communication: Supports a wide range of network protocols, facilitating integration into SCADA/DCS systems to achieve remote monitoring and diagnosis.
___________________________________________________________________________________________
4. Structure and Composition
Power Supply Unit: High-voltage rectifier bridge and DC link.
Inverter Unit: Includes IGBT power modules and inverter bridge, responsible for power conversion.
Control Unit: Core microprocessor, responsible for command parsing, logical operations, and PWM generation.
Cooling System: High-efficiency cooling fan and heat sink to ensure heat dissipation requirements during high-load operation.
___________________________________________________________________________________________
5. Application Fields
General Mechanical Transmission: Constant speed operation and speed regulation control of fans, pumps, compressors, conveyors, etc.
Precision Motion Control: Vector control of machine tool spindles and textile machinery, requiring high-precision torque and speed control.
Injection Molding and Packaging Machinery: Used for controlling the main drive motor in injection molding machines, requiring good torque characteristics and braking performance.
___________________________________________________________________________________________
6. Installation and Maintenance
Installation Notes
- Must be installed in a well-ventilated environment with appropriate temperature (recommended 5℃-40℃).
- The cabinet should be kept clean to avoid dust accumulation affecting heat dissipation.
- Wiring must follow the product manual to ensure reliable grounding and that the cross-sectional area of the protective cable meets the current capacity requirements.
___________________________________________________________________________________________
Maintenance Recommendations
- Regularly check if the wiring terminals are loose, especially the input and output terminals.
- Clean the heat sink fan to ensure normal fan speed.
- Regularly read the operation log through the built-in diagnostic function or communication interface to prevent potential faults.
————————————————————————————————-
