Allen-Bradley 1336-QOUT-SP17A
1. Overview
The Allen-Bradley 1336-QOUT-SP17A is an output tester specifically designed for 1336 series inverters (such as 1336-F, 1336-BDB, 1336-EN, etc.). This device is used during maintenance, troubleshooting, and quality inspection phases to verify whether the inverter’s output signal quality and parameter settings meet standards, thereby ensuring the inverter can operate normally.
2. Specifications
|
Specification
|
Typical Value
|
Unit
|
Remarks
|
|---|---|---|---|
|
Applicable Voltage Range
|
110 – 240 V
|
–
|
Suitable for most industrial standard voltages
|
|
Output Current Capacity
|
10 – 15 A
|
–
|
Capable of supporting testing needs of common inverters
|
|
Display Accuracy
|
±0.5%
|
%
|
High-precision display
|
|
Display Type
|
LCD
|
–
|
Multilingual display, easy to read
|
|
Power Supply
|
Alternating Current (AC)
|
V
|
Built-in power adapter
|
|
Dimensions
|
197.0 x 171.5 mm
|
–
|
Portable design
|
|
Weight
|
Approx. 1.5 kg
|
–
|
Lightweight and easy to carry
|
________________________________________________________________________________________________________________________________
3. Product Features
- Portable Design: Compact size (approx. 20cm x 17cm) and lightweight, convenient for on-site carrying and use.
- High-Precision Detection: Equipped with built-in high-precision sensors and signal conditioning circuits to ensure the accuracy of output waveform and parameter measurement.
- Multifunctional Display: Supports displaying multiple key parameters such as voltage, current, frequency, and waveform distortion.
- High Safety: Features overload protection and short-circuit protection functions, ensuring safe and reliable use.
- Strong Compatibility: Customized for 1336 series inverters, capable of accurately reading and parsing the communication protocols and data formats of this series of equipment.
________________________________________________________________________________________________________________________________
4. Structure and Composition
|
Component
|
Function
|
|---|---|
|
Display Panel
|
LCD display screen, real-time display of test results, waveforms, and parameter values.
|
|
Input/Output Interface
|
Interface for test leads connected to the inverter’s output terminal (usually 3-pin or 4-pin plug).
|
|
Operation Knob
|
Used for selecting test modes, adjusting parameters, and browsing menus.
|
|
Power Adapter
|
AC power input module, providing the working voltage required by the instrument.
|
|
Protective Enclosure
|
Metal or high-strength plastic enclosure, preventing static electricity and external interference.
|
________________________________________________________________________________________________________________________________
5. Application Areas
- Inverter Maintenance: Used to quickly check the quality of inverter output during factory or on-site maintenance.
- Troubleshooting: Locates the causes of inverter faults, such as output waveform distortion and parameter drift.
- Factory Inspection: Used for quality control before inverter delivery, ensuring the output performance of each device meets standards.
- Technical Support: An essential tool for Rockwell Automation technicians when providing on-site technical support to customers.
________________________________________________________________________________________________________________________________
6. Installation and Maintenance
- Unboxing Inspection: Check if the instrument enclosure is damaged and if accessories (test leads, adapter, user manual) are complete.
- Connecting Test Leads: Connect the input interface of the tester to the output terminal of the 1336 series inverter, ensuring a secure connection.
- Power Connection: Plug the instrument into a power socket and turn on the power switch.
- Parameter Setting: Select the test mode as needed (such as voltage test, current test, or waveform analysis).
- Reading Results: Observe the real-time values and waveforms on the LCD display and record abnormal data.
- Daily Maintenance: Unplug the test leads after use, regularly wipe the instrument surface with a dry cloth, and avoid storing in a humid environment.
————————————————————————————————-
