Allen-Bradley 1336-BDB-SP3C
1. Product Overview
Product Type: Industrial Ethernet Switch
Primary Function: Connects various industrial devices such as PLCs, drives, sensors, HMIs, and host computers to enable fast, stable data exchange.
Operating Environment: Built for harsh industrial conditions with resistance to dust, moisture, and vibration, ensuring reliable operation in demanding settings.
Primary Function: Connects various industrial devices such as PLCs, drives, sensors, HMIs, and host computers to enable fast, stable data exchange.
Operating Environment: Built for harsh industrial conditions with resistance to dust, moisture, and vibration, ensuring reliable operation in demanding settings.
___________________________________________________________________________________________________________________________________________
2. Key Specifications
| Parameter | Value | Description |
|---|---|---|
| Ports | 8 × RJ45 | Supports 10/100/1000Base‑T for high‑speed connectivity |
| Transfer Rate | 10/100/1000 Mbps | Full‑duplex support for improved throughput |
| Protection Class | IP30 | Basic dust and splash resistance |
| Operating Temperature | 0°C to +60°C | Suitable for typical industrial environments |
| Storage Temperature | -40°C to +85°C | Withstands extreme storage conditions |
| Power Supply | 24V DC (typical) | Compatible with standard industrial power systems |
___________________________________________________________________________________________________________________________________________
3. Product Features
Fanless DesignRuns silently and eliminates fan‑related failures, making it ideal for clean‑room environments.
Metal HousingProvides excellent heat dissipation and mechanical strength, protecting against shocks and vibrations.
Advanced Network ManagementSupports VLAN, QoS, IGMP snooping, STP/RSTP, and other management features to ensure secure and stable network operation.
Flexible InstallationCan be wall‑mounted, DIN‑rail mounted, or placed on a desktop for easy deployment.
___________________________________________________________________________________________________________________________________________
4. Structure and Components
- Switching Chip: Responsible for fast packet forwarding and processing.
- Metal Enclosure: Provides physical protection and heat dissipation.
- 8 RJ45 Ports: For connecting industrial devices.
- Power Input: Accepts 24V DC power.
___________________________________________________________________________________________________________________________________________
5. Typical Applications
- Industrial Automation: Connects PLCs, HMIs, and SCADA systems.
- Transportation: Used in railway signaling and metro control systems.
- Building Automation: Supports BMS and security monitoring networks.
- Power Industry: Used in distribution automation and protection relays.
- Machine Manufacturing: Connects CNC machines and robotic control systems.
__________________________________________________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation:
- Avoid exposure to water or corrosive gases.
- Ensure proper grounding of the metal enclosure to prevent static buildup.
- Use shielded industrial Ethernet cables and avoid routing alongside high‑power cables to reduce interference.
Maintenance:
- Regularly check port LEDs and monitor for overheating.
- Periodically update firmware as recommended by the supplier to fix vulnerabilities and improve performance.
————————————————————————————————-
