1. Overview

2. Specifications

• Series: 1336 Series
• Mounting Type: Panel Mount
• Module Width: 0.75 inches (19.05 mm)
• Rated Voltage: Usually 240 VAC
• Rated Current: Usually 60 A
• Pole Number: 2 Poles (B015 indicates 2 poles, single-row design)
• Terminal Material: Copper or tinned copper (standard); silver-plated copper may be used for high-load applications
• Cable Specification: Supports 1/0 to 6 AWG cables

_____________________________________________________________________________________________________________

3. Product Features

• Safety and Reliability: Complies with industrial standards to ensure the safety of electrical connections.
• Modular Design: Enables quick replacement and maintenance, reducing downtime.
• High Current-Carrying Capacity: Rated at 60 A, suitable for medium-load circuits.
• Compact Size: 0.75-inch width facilitates layout on panels with limited space.

_____________________________________________________________________________________________________________

4. Structure and Composition

• Conductive Sheet: Usually made of copper, possibly with tin or silver plating, providing low-impedance connections.
• Threaded Components: Used to fix cables, ensuring they are not easily detached due to mechanical tension.
• Insulator: Made of polymer materials, providing electrical insulation protection.
• Clips and Sheaths: Used to fix the position of the terminal block on the panel.

_____________________________________________________________________________________________________________

5. Application Fields

• Industrial Automation: Power supply access for field devices such as PLCs, inverters, and sensors.
• Mechanical Manufacturing: Control cabinets for CNC machine tools, injection molding machines, and packaging machinery.
• Process Control: Instrument wiring in fields such as chemical engineering, petrochemicals, and pharmaceuticals.
• Power Distribution Systems: Branch circuit connections in low-voltage distribution cabinets.
