1. Overview

2. Technical Specifications

• Rated Power: 15 kW (approximately 20 HP)
• Motor Specifications: Suitable for motors ranging from 0.75 – 20 kW (1 – 27 HP)
• Input Voltage: 115/230/460 VAC, three-phase, 50/60 Hz
• Output Voltage: 0 – 460 VAC, three-phase
• Control Method: V/Hz (Voltage/Frequency) control
• Braking Method: Equipped with braking diode or braking resistor
• Display Interface: With LCD display for showing parameters and fault information

___________________________________________________________________________________________________________________________

3. Key Features

• Modular Design: Compact structure, easy for cabinet installation, and supports distributed installation.
• Digital Precision Control: Possesses precise digital speed control capability with high speed accuracy.
• Versatility: Supports multiple functions such as soft start, soft stop, braking, ramp control, and throttle/brake control.
• User-Friendliness: Equipped with a Chinese/English LCD display, making parameter setting and fault diagnosis simple and intuitive.
• Reliability: Designed with industrial-grade components, featuring safety mechanisms such as overload protection, short-circuit protection, and overvoltage/undervoltage protection, adaptable to harsh electromagnetic environments.

___________________________________________________________________________________________________________________________

4. Construction and Components

• Rectifier: Converts input AC voltage to DC voltage.
• DC Link: Energy storage capacitors are used for filtering and smoothing DC voltage.
• Inverter: Converts DC voltage to AC voltage of variable frequency and outputs it to the motor.
• Control Circuit: Includes microprocessor and signal processing circuit, responsible for calculating V/Hz ratio and generating PWM pulses.
• LCD Panel: Displays operating parameters (such as frequency, speed, current) and fault codes.
• Brake Unit: Used to handle the braking energy of the motor and prevent motor overshoot.

___________________________________________________________________________________________________________________________

5. Application Areas

• Mechanical Manufacturing: Used to control the spindle motors of machine tools such as lathes, milling machines, and drilling machines.
• Mining and Metallurgy: Drives large motors for ore crushing, belt conveying, and rolling mill operation.
• Pumps and Fans: Adjusts the flow rate and pressure of fluid conveying systems.
• General Industrial Automation: Applied to various production line equipment that requires motor speed control.

___________________________________________________________________________________________________________________________

6. Installation and Maintenance

• Installation Clearance: It is recommended to reserve 152.4 mm (6 inches) of space at the top, bottom, left, and right of the equipment, and 101.6 mm (4 inches) of horizontal spacing between equipment to ensure heat dissipation and easy maintenance.
• Power Supply Connection: Ensure that the input power voltage and frequency meet the specifications, and correctly connect the L1, L2, L3 three-phase power supplies.
• Grounding: The metal housing of the equipment must be reliably grounded to prevent electric shock and electromagnetic interference.
• Motor Wiring: Select star or delta wiring according to the motor rated voltage, and ensure correct phase sequence.
• Parameter Setting: Perform parameter setting through the keyboard and LCD display, or use Allen-Bradley’s programming software (such as RSLogix 500) for remote configuration.
• Regular Inspection: Check if the heat sink is dusty, if the capacitors are swollen, and if the wiring terminals are loose or corroded.
