Allen-Bradley 1336-B007-EOD-F
1. Overview
The Allen‑Bradley 1336S‑B007‑AN is a low‑power variable frequency drive (VFD) belonging to the PowerFlex 1336S series. Designed by Rockwell Automation for high performance and reliability, this series is widely used across industrial automation applications.
• Product Rating: The 1336S‑B007‑AN typically corresponds to a 2HP (approximately 1.5kW) drive. Exact ratings may vary slightly by region or production year.• Control Language: This model uses the AN (Allen‑Bradley Native) control language.• Enclosure Type: No Box configuration, providing a compact standalone drive unit.
_______________________________
2. Specifications
• Rated Power: 2HP (1.5kW)• Rated Voltage: 460V (typical configuration) • Rated Current: Approximately 4.5A (based on power rating)
• Phase: 3‑phase (3PH)
• Motor Control: Suitable for V/Hz (constant voltage/frequency) or constant torque applications
• Efficiency: High efficiency, compliant with IE3 or higher standards
• Protection Class: NEMA 4X (dust‑tight and water‑resistant)
• Control Language: AN (Allen‑Bradley Native)
_____________________________
3. Features
• High Performance and Reliability: Built on the PowerFlex 1336S platform, delivering Rockwell’s proven quality for demanding industrial environments. • Compact Design: The No Box configuration saves space and is ideal for cabinet or control panel installation.• Easy Integration: Uses Allen‑Bradley’s standard AN control language, enabling seamless integration with Rockwell PLCs such as ControlLogix and CompactLogix.
• Advanced Protection: Includes overload, overcurrent, overvoltage, undervoltage, and phase‑loss protection.
• Communication Capabilities: Supports industrial networks such as EtherNet/IP for flexible connectivity.
____________________________
4. Structure & Components
• Housing: Metal enclosure with NEMA 4X protection for dust and water resistance.• Control Panel: Front‑mounted interface with a digital display and keypad for parameter configuration and status monitoring.• Internal Circuitry: Includes rectifier, DC bus capacitors, IGBT inverter, and a digital signal processor (DSP) for precise control.
________________________
5. Applications
• Mechanical Drives: Speed control for low‑power motors in conveyors, mixers, and similar equipment.
• Automation Systems: Works with PLCs to achieve accurate motion control.
• Energy‑Saving Retrofits: Replaces fixed‑speed motors in variable‑speed applications to reduce energy consumption.
————————————————————————————————-
