Allen-Bradley 1336-B007-EAD-S

1. Product Overview

• Product Name: 1336‑B007‑EAD‑S
• Brand/Series: Allen‑Bradley 1336 Series, Rockwell Automation
• Function: Adjustable Frequency Drive (VFD)
• Motor Rating: 7 HP (approximately 5.2 kW)
• Primary Use: Speed and torque control for AC induction motors

2. Key Technical Specifications

• Output Power: 7.6 kVA (varies by configuration)
• Input Voltage: 460V AC (some models support 380V / 415V)
• Output Current: 9.6 A (for 7 HP motors)
• Power Factor: 0.95
• Communication: RS485 or Ethernet/IP (depending on model)
• Enclosure Code: “S” indicates a specific enclosure type (varies by NEMA rating)

3. Product Features

• Energy Efficient: Reduces energy consumption by adjusting motor speed based on demand.
• Wide Compatibility: Works with most industrial AC induction motors.
• Precision Control: Supports multiple control modes such as V/F and vector control.
• Industrial‑Grade Reliability: Built to withstand harsh factory environments.

4. Construction & Components

• Rectifier: Converts incoming AC power to DC.
• Inverter: Converts DC back to variable‑frequency AC for motor control.
• Control Unit: Features a microprocessor for handling speed commands, acceleration, deceleration, and other functions.
• Cooling System: Includes heat sinks and fans to maintain optimal operating temperatures.

5. Typical Applications

• Production Lines: Packaging machines, conveyors, and material handling systems.
• Pumps & Fans: Regulate flow and pressure efficiently.
• Cranes & Elevators: Ensure smooth starts and stops.
• Injection Molding & Printing Machines: Require precise motion control.

6. Installation & Maintenance

Installation

• Power Connection: Ensure input voltage matches the drive’s rating (e.g., 460V three‑phase).
• Grounding: Proper grounding is essential for EMC compliance and safety.
• Ventilation: Install in a well‑ventilated area and avoid blocking cooling fans.

Commissioning

• Parameter Setup: Configure motor type, voltage, and frequency range via the front panel or software such as RSLogix 5000.
• Signal Checks: Verify wiring for external sensors and feedback devices.

Maintenance

• Cleaning: Regularly remove dust and check fan operation.
• Inspection: Ensure input/output terminals are tight to prevent vibration‑related loosening.
