Allen-Bradley 1336-B007-EAD-F
1. Product Overview
The Allen-Bradley 1336-B007-EAD-F is a 7 HP (approximately 5.2 kW) AC variable frequency drive (VFD) under the Allen-Bradley brand of Rockwell Automation. As part of the 1336 series inverters, it is mainly used for precise control of the speed and torque of AC motors, and is widely applied in the field of industrial automation.
_____________________________________________________________________________
2. Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Power
|
7 HP (approximately 5.2 kW)
|
|
Voltage
|
460V AC
|
|
Frequency Range
|
0 – 250 Hz
|
|
Control Mode
|
EAD (Enabling Adjustable Torque)
|
|
Phase
|
Three-phase
|
|
Cooling Method
|
Fan-cooled
|
|
Dimensions
|
Standard DIN RACK / PANEL dimensions (please refer to the actual product manual for specific dimensions)
|
|
Interface
|
Multiple I/O options (including analog and digital input/output)
|
_____________________________________________________________________________
3. Product Features
- Adjustable Torque Control (EAD): Supports the Enabling Adjustable Torque function, allowing users to directly set the torque threshold inside the inverter, suitable for occasions requiring precise torque control.
- Flexible I/O Options: Provides rich input and output interfaces, facilitating integration into various automation systems.
- Wide Frequency Range: Supports an output frequency of 0-250 Hz, offering a broad speed control range.
- Robust and Durable: As a brand of Rockwell Automation, Allen-Bradley boasts high reliability and industrial-grade quality assurance.
_____________________________________________________________________________
4. Structure and Composition
- Housing: Metal housing equipped with a cooling fan.
- Circuit Board: Including power module, control module, etc.
- Interface Panel: Provides various connection terminals for easy wiring.
- Display/Indicator Lights: Used for status display (some models may be equipped with an LCD display).
_____________________________________________________________________________
5. Typical Application Areas
- Industrial Automation: General mechanical transmission control, such as belt conveyors and screw conveyors.
- Petrochemical and Chemical Industry: Used in equipment requiring precise torque control such as mixing and stirring.
- Power and Energy: Speed control of fans and pumps.
- Building Facilities: Control of fans and water pumps in HVAC (Heating, Ventilation, and Air Conditioning) systems.
_____________________________________________________________________________
6. Installation and Maintenance Recommendations
- Electrical Connection: Ensure the power supply voltage complies with 460V AC, and correctly connect the power cables and control cables.
- Heat Dissipation: During installation, maintain sufficient heat dissipation space around the inverter, avoid stacking flammable items, and ensure the cooling fan works normally.
- Grounding: Correct grounding is crucial to ensure the normal operation of the inverter and prevent electromagnetic interference.
- Parameter Setting: Configure the corresponding parameters (such as motor rated current, acceleration/deceleration time, torque setting, etc.) in the control panel or upper computer software according to the specific motor and load requirements.
- Regular Inspection: Regularly check the tightness of input and output terminals, cooling fans, and internal connecting wires.
————————————————————————————————-
