Allen-Bradley 1336-B005-EAD-L

1. Overview

2. Specifications

• Measurement Range: 230V / 400V AC (single‑phase / three‑phase)
• Current Measurement: 100A (with current transformer)
• Power Factor Range: 0.0 – 1.0
• Harmonic Analysis: 50/60Hz fundamental frequency (0.1 – 100Hz)
• Data Storage: Built‑in memory card (typically SD card) for long‑term data logging
• Communication Interfaces: USB, Ethernet, Wi‑Fi (depending on configuration)
• Battery Life: Long‑lasting battery for portable field use

____________________________________________________________________________________________

3. Key Features

• High‑Precision Measurement: Advanced sampling technology ensures accurate measurement of power factor, harmonics, and other critical parameters.
• Portable Design: Compact and lightweight, ideal for fieldwork and rapid deployment.
• Comprehensive Analysis: In addition to basic power measurement, it provides harmonic analysis, flicker analysis, and other power quality evaluation functions.
• Real‑Time Display & Storage: Supports real‑time waveform viewing and data storage to an SD card or network transmission.

_________________________________________________________________________________________

4. Structure and Components

• Main Unit: Equipped with a high‑resolution touchscreen for displaying waveforms and parameters.
• Current Transformer (CT): Used for AC current measurement (usually an optional accessory).
• Measurement Clamps: Clamp‑on voltage probes for safe and convenient voltage measurement.
• Communication Modules: Including USB, Ethernet, and optional Wi‑Fi.
• Battery and Power Supply: Provides portable power for field operations.

_________________________________________________________________________________________

5. Application Areas

• Industrial Electrical System Maintenance: Monitor motor performance, analyze harmonics, and assess overall power quality.
• Motor Commissioning: Help engineers evaluate power factor, efficiency, and other key motor parameters.
• Troubleshooting: Quickly identify voltage drops, harmonic interference, and other electrical anomalies.
• Building Energy Management: Analyze and optimize the energy efficiency of building electrical systems.

_________________________________________________________________________________________

6. Installation and Maintenance

Installation

Maintenance

• Regular Calibration: Ensure long‑term measurement accuracy.
• Keep Interfaces Clean: Prevent oxidation of USB and network ports.
• Battery Check: Verify battery level or charge before field use.
• Data Backup: Regularly export and back up logged data to prevent loss.

————————————————————————————————-
