I. Overview

The ABB WN2660-6EG 3BHL000986P7002 is a high-performance and high-reliability industrial power supply module, specifically designed for industrial automation systems. It can provide stable DC power for various automation equipment and is suitable for a variety of harsh industrial environments. The module adopts a modular design, which is convenient for installation and maintenance, and at the same time has multiple protection functions to ensure the safe operation of the system.

• Input voltage: 85-264VAC (wide input voltage range, adaptable to different power grid environments)
• Output voltage: 24VDC (other voltages optional, such as 12V, 36V, 48V)
• Output current: 5A
• Power: 247W
• Efficiency: High
• Operating temperature range: -25°C to +70°C (some data show -40°C to +85°C)
• Dimensions: 106mm x 103mm x 138mm (standard DIN rail mounting size)
• Cooling method: Natural cooling
• Certifications: Compliant with CE, UL and other safety certification standards

• High reliability: Adopts industrial-grade design, suitable for harsh industrial environments, with high reliability and long service life.
• High precision: Provides high-precision voltage output to ensure stable operation of equipment.
• Easy integration: Modular design, supports DIN rail installation, convenient for integration with other equipment.
• Safety: Equipped with multiple protection functions, such as overload protection, short-circuit protection, overvoltage protection, etc., to ensure the safety of equipment and personnel.
• Low harmonic interference: Compliant with EMC standards such as EN 61000-3-12, reducing harmonic interference to the power grid.
• Silent operation: Fanless design, runs quietly.

• Input terminal: Supports a wide range of input voltages (85-264VAC), adaptable to different power grid environments.
• Output terminal: Provides stable 24VDC output, supporting various loads.
• Protection circuit: Includes overload protection, short-circuit protection, overvoltage protection, etc., to ensure system safety.
• Installation method: Uses DIN rail mounting, convenient for installation and maintenance.
• Heat dissipation design: Natural cooling, no need for additional heat dissipation equipment.

• Industrial automation: Provides stable power for various automation equipment.
• Process control: Used in industrial process control systems.
• Building automation: Applied in building automation systems.
• Pumping stations and automation control systems: Particularly suitable for environments such as pumping stations and automation control systems.
• Manufacturing, energy, infrastructure: Suitable for industrial automation systems that require high precision and high performance.

• Uses DIN rail mounting, which is simple to install and convenient for maintenance.
• Supports redundant or parallel operation, facilitating system expansion and maintenance.

• Regularly check the operating status of the power module to ensure its normal operation.
• Replace damaged components in a timely manner to ensure the stability and safety of the system.
• Provides detailed installation manuals and user guides to ensure smooth setup and maintenance.
