Operating Voltage Range:24V DC

Output Current Range:10mA to 100mA

Isolation Voltage:2500V AC

Input Signal Range:-10V to +10V or 4-20mA

Power Consumption:Max. 3W

Temperature Range:-25°C to +70°C

    Introducing the ABB TET 106 Isolated Amplifier Module, a robust solution designed to enhance the precision of your industrial control systems. This module is meticulously engineered to provide unparalleled reliability and efficiency, ensuring smooth operation in harsh environments. Its wide operating temperature range (-40°C to +85°C) makes it suitable for applications in extreme conditions, from cold storage facilities to hot manufacturing floors.

    Featuring a high isolation voltage of 1000 VAC/1 min, this module ensures safety and prevents any potential interference between different parts of your system. It operates on a versatile power supply voltage of 10 to 36 VDC, allowing seamless integration with various power sources commonly found in industrial settings.

    With its single-channel output, the ABB TET 106 module offers ±5 to ±10V of output voltage range, providing the flexibility to match the needs of diverse control signals. The input impedance of 10 kΩ ensures minimal loading effects, maintaining the integrity of the input signals. Moreover, its low current consumption of ≤ 5 mA contributes to energy efficiency and system longevity.

    This isolated amplifier module is crafted with precision and quality, making it an ideal choice for applications requiring high accuracy and isolation, such as motor control, process control, and automation systems. It supports seamless data transmission without degradation, enhancing system performance and reliability.

    Designed for durability and ease of integration, the ABB TET 106 Isolated Amplifier Module is compatible with a wide range of industrial control systems. It simplifies the installation process, reducing downtime and streamlining maintenance procedures. Trust in ABB’s commitment to innovation and quality, backed by extensive experience in the field of industrial automation.
