ABB PM861K01

Parameters

• Processor type: Intel Core i7
• Main frequency: 2.6 GHz
• Memory capacity: 8 GB
• Storage capacity: 128 GB SSD
• Operating system: Windows 10 IoT Enterprise
• Dimensions: 220 mm x 160 mm x 45 mm
• Weight: 1.5 kg
• Power supply voltage: 24 V DC
• Operating temperature range: -20℃ to +60℃
• Protection class: IP20

Product Features

• High performance: Adopts advanced processor technology to ensure stable and efficient performance in complex control tasks.
• High reliability: Designed for harsh industrial environments, with high reliability and stability.
• Easy maintenance: Modular design facilitates installation and maintenance.
• Flexible configuration: Supports multiple communication interfaces such as Ethernet, serial ports, and CAN bus, adapting to different application scenarios.
• Openness: Compatible with multiple operating systems, making it easy to integrate into existing systems.

Structure and Composition

• Central Processing Unit (CPU): Responsible for processing control tasks.
• Baseplate (TP830): Provides physical support and connections.
• Bus terminators: Including CEX bus terminators, Modulebus terminators, and RCU-Link terminators, used to connect other modules.
• Memory backup battery: Ensures data is not lost in case of power failure.
• Power plug: Provides stable power supply.

Application Fields

• Manufacturing: Automated production lines, robot control.
• Energy industry: Automated control of power plants and substations.
• Petrochemical industry: Precise control of petrochemical plants.
• Paper industry: Control of paper production lines.
• Water treatment industry: Automated control of water treatment plants.
• Automotive manufacturing industry: Control of automotive production lines.

Installation and Maintenance

• Installation method: Usually installed on a DIN rail, facilitating integration into control cabinets.
• Maintenance: The modular design makes installation and maintenance easier, supporting remote diagnosis and maintenance.
• Compatibility: It can be used with other AC 800M series products to form a complete control system.
