Frequency Range:1.5 – 30 MHz

Operating Voltage:220 VAC

Filtering Capability:High-pass, low-pass, band-pass, and band-stop filters

Impedance:50 ohms

Attenuation:Up to 50 dB

Size:Compact design, suitable for space-constrained environments

Material:Corrosion-resistant stainless steel housing

    The ABB PEP-A-220VAC RF FILTER is a robust solution for RF signal filtering, ensuring clear and noise-free signals in demanding industrial environments. Its passive design guarantees reliability without the need for active power supply, making it ideal for a wide range of applications including telecommunications, radar systems, and test equipment.

    Engineered with dielectric and metal components, this filter offers exceptional durability and efficiency, capable of handling extreme temperature conditions (-40°C to +85°C) without compromising performance. The compact panel mount design facilitates easy integration into existing setups, minimizing space requirements and simplifying installation processes.

    With an operating voltage of 220VAC, this filter is compatible with various power sources commonly found in industrial settings, ensuring seamless operation regardless of the power infrastructure. The bandwidth of 1.5 MHz to 30 MHz covers a broad spectrum of frequencies, making it suitable for a multitude of applications requiring precise RF signal filtering.

    Featuring a low insertion loss of less than 0.1 dB and a high attenuation of 50 dB at 1.5 MHz and 40 dB at 30 MHz, the ABB PEP-A-220VAC RF FILTER delivers superior signal integrity, effectively mitigating unwanted signals and interference. This ensures optimal performance in critical applications where signal purity is paramount.

    Ideal for industries seeking reliable and efficient RF filtering solutions, the ABB PEP-A-220VAC RF FILTER is a testament to ABB‘s commitment to delivering innovative products that meet the evolving demands of modern technology.
