Operating Voltage:24V DC

Power Consumption:≤ 1W

Communication Protocol:DeviceNet, EtherCAT, CANopen

Number of Inputs/Outputs:16 inputs / 16 outputs

Current Draw (max):≤ 100mA

Operating Temperature:-20°C to +60°C

Enclosure Type:IP20

Dimensions (W x H x D):55mm x 55mm x 32mm

    The ABB DSQC378B 3HNE00421-1 Robot Module boasts an innovative design that supports seamless integration with a wide array of robotic systems. Its robust construction ensures durability in harsh industrial environments, making it ideal for applications requiring precise control and reliability.

    Equipped with 8 digital inputs and 8 digital outputs, this module offers a flexible platform for controlling various components within robotic setups. The compatibility with DeviceNet, EtherCAT, and Profinet communication protocols facilitates efficient data exchange, enhancing system performance and interoperability.

    Featuring an operating voltage of 24V DC and a current limit of ≤25mA for inputs and ≤500mA per channel for outputs, the DSQC378B 3HNE00421-1 ensures stable power supply and signal integrity. This module is engineered to operate within a temperature range of -20°C to +55°C, ensuring reliable performance across diverse climates.

    With dimensions of 100mm x 35mm x 100mm and a lightweight of 0.2kg, the module is compact and easy to install, minimizing space requirements and reducing installation time. Its small size does not compromise functionality, making it a valuable asset in optimizing robotic workstations.

    The ABB DSQC378B 3HNE00421-1 Robot Module is not just about its technical specifications; it’s about delivering enhanced automation capabilities to your robotic systems. Whether you’re looking to upgrade existing equipment or integrate new functionalities, this module offers the precision, reliability, and flexibility needed to elevate your operations.
