Manufacturer:ABB

Model Number:DSDX404

Module Type:Digital Input

Channels:16 channels

Voltage Range:10-30 VDC

Input Impedance:1 kΩ

Response Time:1 ms

Operating Temperature Range:-25°C to +70°C

Protection Rating:IP20

Dimensions:100 mm x 30 mm x 65 mm

Weight:0.2 kg

    The ABB DSDX404 Data Acquisition Module is an essential component for industrial automation systems, offering robust performance and reliability. Its 16 input channels support a wide range of sensor types, ensuring precise data acquisition. With a resolution of up to 12-bit, it delivers high accuracy measurements, making it suitable for demanding industrial environments. The module supports high-speed sampling rates of up to 100 kS/s, enabling real-time monitoring and control. The built-in Modbus TCP/IP and Ethernet/IP communication interfaces allow seamless integration with existing systems, facilitating easy data transfer and management. Designed for harsh conditions, the DSDX404 is rated IP65, providing protection against dust and water ingress. Its compact size (190 mm x 110 mm x 50 mm) makes it easy to install in tight spaces, while its lightweight design (0.5 kg) ensures minimal impact on system weight. Operating within a broad temperature range (-40°C to +85°C), the DSDX404 is highly versatile and reliable, even in extreme conditions.
