ABB AI930N
ABB AI930N is part of ABB’s industrial automation solutions, specifically designed for industrial applications requiring high-precision analog signal acquisition. This module supports multiple industrial standard protocols, such as HART protocol, and provides reliable analog signal input functionality, suitable for various industrial automation scenarios.
- Power Requirement: 24 V DC
- Operating Temperature Range: -10°C to +60°C
- Input Voltage Range: 4…20 mA (HART Protocol)
- Sampling Rate: Up to 1 kHz
- Communication Interfaces: Ethernet, RS485
- Dimensions: 120mm × 80mm × 30mm
- Weight: 200g
- Protection Level: IP20
- Certification Standards: CE, UL
ABB AI930N employs advanced signal processing technology to accurately collect and convert analog signals, suitable for inputs from industrial sensors such as temperature, pressure, and flow sensors.
The module uses high-quality electronic components and strict manufacturing processes to ensure stable operation in industrial environments.
Users can configure the module via software or hardware according to actual needs, supporting multiple I/O signal types for easy connection with various sensors and actuators.
The module features real-time data processing capability, enabling quick response to changes in industrial processes.
ABB AI930N seamlessly integrates with ABB’s automation systems, ensuring efficient and reliable operation.
ABB AI930N primarily consists of the following components:
The module provides 8 analog input channels, supporting multiple signal types such as voltage, current, and temperature.
The built-in signal conditioning circuit amplifies, filters, and converts input signals to ensure accuracy and stability.
Supports Ethernet and RS485 communication interfaces for easy data exchange with upper computers or PLC systems.
The module is powered by 24 V DC to ensure stable operation in industrial environments.
With an IP20 protection rating, it is suitable for general industrial environments.
ABB AI930N is widely used in the following industrial sectors:
Monitors parameters like temperature, pressure, and flow on production lines to achieve precise control.
Used in chemical, petroleum, and power industries to monitor and control process parameters.
Applied in environmental monitoring and control for buildings, such as air conditioning and lighting systems.
Integrates with ABB’s intelligent wastewater solutions to monitor and control key parameters in the wastewater treatment process.
Works with ABB’s robot control systems to monitor and control parameters like temperature and pressure in robot joints.
- Ensure the installation environment meets temperature and humidity requirements.
- Mount the module on an IP20-protected rail, ensuring correct power and signal connections.
- Connect to the upper computer or PLC system via Ethernet/IP.
- Regularly inspect the module’s connections and power status to ensure stable signal transmission.
- Use ABB-provided software tools for configuration and monitoring to ensure normal operation.
- Ensure power is off during maintenance to avoid damaging the module.
- If signal anomalies occur, check whether the input channels and signal conditioning circuit are normal.
- If communication is interrupted, verify the correct connection of Ethernet and RS485 interfaces.
- If the module fails to start, check the power supply and fuse.
